Product data

SpecificationDetails
Nominal capacity191 - 510 mtph210 - 562 stph
Max. feed size500.0 mm19.7 in.
Motor power220 kW295 hp
Closed side setting (CSS) range25.0 - 57.0 mm1.0 - 2.2 in.
Eccentric tdrow range20.0 - 36.0 mm0.8 - 1.4 in.
Mantles (inner liners)A, B
Concaves (outer liners)EC, C, MC
No of chambers3
Weight21,637 kg47,699 lb
Automation (ASRi)Optional
Lubrication tankStandard
Offline lubrication filtration unitOptional


The chambers available are:

CS440-NOMINAL CAPACITY*(MTPH)



ConcaveECCMC
Max. feed size (mm)F90332295222
F100500445335
Max. motor power (kW)
220220220
Eccentric tdrow (mm)
20-3620-3620-36
CSS (mm)25--191-222
29--206-313
32262272-316218-330
35276-365287-435229-348

38

290-440301-456241-365
41304-461315-478252-382
44318-482330-500264-400
48336-510349-461279-369
51350-463363291
54364-422--
57378--
Mantle
A/B/AA/B/SA/B/S

*Note: The processing capacity of the CS440 cone crusher may vary with different materials and feeding sizes.

Request a quoteMobiles tracked brochure

Our range cone crushers

CS660 Cone Crusher

CS660 Cone CrusherCS660

Nominal capacity314 - 908 mtph (346 - 1,000 stph)

Max. feed size622.0 mm (24.5 in.)

Motor power315 kW (422 hp)

Live Chat
CS315B Cone Crusher

CS315B Cone CrusherCS315B

Nominal capacity381 - 1270 t/h

Max. feed size

Motor power315 kW

Live Chat
CS240D Cone Crusher

CS240D Cone CrusherCS240D

Nominal capacity90 - 336 t/h

Max. feed size

Motor power240 kW

Live Chat

Case stories

5000TPH Limestone Crusher Plant in Zhumadian

Two 2500-3000tph production lines enter into operation at the same time. In order to ensure both the quality and capacity we configure two sets of PCZ2125 heavy hammer impact crusher for primary crushing 4 sets of shaping hammer crusher a

600TPH Stone Production Line in Liuzhou Guangxi

It is seen the stone production line is next to concrete production base which greatly facilitates production. Many concrete manufacturers consider constructing their own stone production lines.

600TPH Aggregates Production Line in Quyang Hebei

In aggregates production line hammer crusher works as primary crusher that can crush bulk limestone.

Additional product information

Stationary Cone Crushers 400 - 600 Series - CS440

General Information

The CS440 cone crusher features a hydraulically supported main shaft with both - end support. Its robust design, adjustable eccentric throw, and constant intake opening make it suitable for high - capacity secondary crushing applications.

Key Features

  • Hydroset™ system: Offers safety and setting - adjustment functions, enhancing the crusher's operational flexibility and safety.
  • ASRi™: Automatically adapts the crusher to feed conditions, optimizing its performance and productivity.
  • Unibody mainframe: Ensures optimal strength and reduces maintenance requirements, minimizing downtime and maintenance costs.
  • Lifting from above: Minimizes risks and enables safer maintenance, creating a safer working environment for operators.
  • Excellent in secondary applications: Due to its large feed opening, it is highly effective in secondary crushing operations.
  • Easy to maintain: The design of the crusher allows for straightforward maintenance procedures.
