Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Model | Cavity | Feed opening (mm) | Maximum feed (mm) | Discharge port (mm) | Motor power (kw) | Weight (t) | Capacity (t/h) |
| HPM800 | C1 | 353 | 280 | 38 | 630 | 70 | 616 - 1100 |
| C2 | 297 | 240 | 38 | 522 - 1100 | |||
| C3 | 219 | 175 | 22 | 380 - 1100 | |||
| F1 | 155 | 125 | 20 | 328 - 730 | |||
| F2 | 92 | 75 | 16 | 270 - 730 |
*Note: The processing capacity of the HPM800 cone crusher may vary with different materials and feeding sizes.
Work Process The raw materials (bulk limestone)are first sent by the ZGC vibrating feederto PCZ1615 heavy hammer crusher for primary crushing. Then the materialsare processed by two sets of 3YKZ2470 vibrating screen for gradation. Those with qualifie
Since there is a large quantity of fine-grained particle in the material the pre-screening shall be conducted before secondary and fine crushing. If the particle size is small the closed screening should be adopted.
This basic configuration of 500tph production line: PCZ1615 heavy hammer crusher PC1213 hammer crusher ZG1538 feeder 3YKZ2670 vibrating screen*2 2YKZ2670 vibrating screen*2.
The HPM800 Multi-Cylinder Hydraulic Cone Crusher is designed for superlative capacity crushing applications, making it ideal for large-scale operations in industries such as metallurgy, construction, road building, chemistry, and silicate raw material processing. With a maximum feed opening size of 2000 mm and a processing capacity range of 616 - 1100 t/h, the HPM800 is capable of handling extremely high volumes of material.
The HPM800 offers precise control over the discharge opening, ensuring consistent product quality. The single hydraulic cylinder provides accurate adjustments, while the Siemens PLC control system monitors and optimizes performance in real-time. This results in a high proportion of cubic-shaped products and a more uniform particle size distribution.
The HPM800 is built to last, with a robust and durable design that can withstand the demands of continuous operation. The main shaft is supported at both ends, providing additional stability and reducing wear and tear. The advanced sealing system prevents dust and contaminants from entering, ensuring long-term reliability.
The modular design of the HPM800 allows for easy conversion between different crushing stages by simply replacing the fixed cone. This flexibility makes it a versatile choice for various production needs, from coarse to fine crushing. The machine's ability to handle a wide range of materials and sizes adds to its value and utility.
