HPY500

HPY500 Crusher: An Outstanding Model of Crushing Efficiency

I. Advantage Analysis

(1) Powerful Power and Yield

The HPY500 crusher is equipped with a 400kW motor, providing a strong power source for the equipment. This enables it to handle various materials with ease and demonstrates excellent production capacity. Looking at the production data, under different closed - side setting (CSS) settings, its hourly throughput is quite remarkable. For example, at a small CSS, the throughput can meet the needs of refined production; while at a large CSS, the throughput can be significantly increased, sufficient to handle large - scale coarse crushing operations, effectively improving the overall production efficiency and meeting the high - intensity production task requirements of industries such as mining and construction.

(2) Innovative Cavity Design

1. Efficient Crushing Mode

Its crushing cavity adopts an advanced design concept, using high - energy laminating crushing technology. Inside the cavity, materials not only experience the force with the cavity wall, but also strong squeezing and crushing effects between particles. This unique crushing mode makes material crushing more complete and improves the crushing efficiency.

2. High - Quality Product Output

Due to the effective crushing between particles, the produced product has good particle size uniformity and extremely low flake and needle - shaped particle content, which can provide high - quality aggregates for industries such as construction, improving the stability and durability of building structures.

3. Reduced Loss Cost

The mutual crushing between particles shares part of the energy, reducing the direct wear on the cavity wall and wearing parts, thereby reducing the replacement frequency of wearing parts, saving equipment operation costs and maintenance time.

(3) Stable and Reliable Structure

1. High - Strength Material and Process

The frame and main shaft of the HPY500 are made of high - strength alloy steel through precision casting and forging. The combination of this material and process endows the equipment with extremely strong compression and wear resistance, enabling it to easily handle the crushing challenges of medium - hard and above materials, ensuring the stability of the equipment under long - time and high - load operation, reducing the downtime due to equipment failures and ensuring the continuity of production.

(4) Convenient Maintenance Features

1. Intelligent Hydraulic System Assistance

Equipped with an advanced hydraulic system, the two - way iron - passing release hydraulic cylinder can effectively deal with the situation where an iron block accidentally enters the crushing cavity, allowing the iron block to pass through smoothly and avoiding equipment damage. The hydraulic cleaning of the crushing cavity has a large stroke and is not affected by the wear of the liner, and can quickly clean the blocked materials, reducing the need for manual intervention.

2. Easy Liner Replacement

The hydraulic motor drives the adjustment sleeve, which is convenient for accurately adjusting the discharge port. When the liner needs to be replaced, the fixed cone liner and the moving cone liner can be conveniently rotated out without the need for complex frame disassembly operations, greatly simplifying the maintenance process and improving the equipment utilization efficiency.

The HPY500 crusher, with its significant advantages in power, cavity, structure, and maintenance, performs excellently in many crushing application scenarios and is an ideal choice for enterprises pursuing efficient, stable, and high - quality crushing operations.
