Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Model | HST750 | ||
| Cavity Type | H1(Fine) | H2(Medium - Fine) | H3(Ultra - Fine) |
| Feed Opening | 370mm | 195mm | 85mm |
| Minimum Discharge Opening | 25mm | 22mm | 10mm |
| Processing Capacity | 460 - 2130t/h | 525 - 1605t/h | 350 - 885t/h |
| Maximum Installed Power | 750kW | ||
*Note: The processing capacity of the HST750 cone crusher may vary with different materials and feeding sizes.
It’s seen the crusher is installed below the silo; the aggregates are fed into the crusher in a convenient and efficient manner. The corresponding motor equipped ensures equipment to operate according to rated power with low consumption.
This 600t/h production line has the basic configuration of PCZ1615 heavy hammer crusher PC1213 hammer crusher ZG1538 feeder 3YKZ2670 vibrating screen*2 sets 2YKZ2670 vibrating screen*2 sets.
In this stone production line it is easy to carry out maintenance on the devices for example the hammer crusher can be opened by hydraulic pressure in order to repair and maintain the hammerhead without using external tools.
The HST750 comes in H1 (fine), H2 (medium - fine), and H3 (ultra - fine) cavity types. The H1 has a 370mm feed opening and 25mm discharge port, with a capacity of 460 - 2130t/h. H2 has a 195mm feed opening and 22mm discharge port, handling 525 - 1605t/h. H3 has an 85mm feed opening and 10mm discharge port, processing 350 - 885t/h.
Regular maintenance is vital for the HST750. Small - scale repairs, done every 1 - 2 months, involve checking and adjusting wear - parts like bearings and seals, and maintaining the oil and cooling systems. Medium - scale repairs, every 4 - 6 months, include liner replacement and component repair. Large - scale repairs, about every 3 - 4 years, are more comprehensive, such as full disassembly and replacement of key parts to keep the crusher in top shape.
