Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| model | SC660 |
| Max feed size | 560 mm |
| CSS Range | 38 - 83 mm |
| Capacity(by hour) | 318 - 1050 t/h |
| Motor power | 400 kW |
| Dimensions | 2156×2800×5100 mm |
*Note: The processing capacity of the SC660 cone crusher may vary with different materials and feeding sizes.
This 500tph stone production line configured by Xinxiang Dingli in Pingliang Gansu mainly adopts PCZ1615 heavy hammer crusher with hourly capacity of 4200-500 ton ZG2038 vibrating feeder and several sets of our efficient vibrating screen.
Nanshui Building Materials Co., Ltd. and Zhongyu cooperate to build a new 1500 tons of sand and stone processing production line, integrate environmental protection design, and install sewage treatment devices, will pollute the environment, and vigorously promote the smooth progress of local green mine construction work.
Work Process The raw materials (bulk limestone)are first sent by the ZGC vibrating feederto PCZ1615 heavy hammer crusher for primary crushing. Then the materialsare processed by two sets of 3YKZ2470 vibrating screen for gradation. Those with qualifie
The SC - 660 single - cylinder hydraulic cone crusher is the perfect choice for large - scale projects. With a maximum feed size of 560mm, it can handle super - large ores, a feature that the SC - 430 and SC - 440 don't have. The discharge opening adjustment range of the SC - 660 is 38 - 83mm, which can meet the strict requirements for different particle sizes in large - scale production. The 400kW powerful power ensures the stable operation of the SC - 660 even under high - intensity operations.
The processing capacity of the SC - 660 ranges from 318 - 1050t/h, achieving large - scale production. Weighing 36.5 tons and having an overall dimension of 2156×2800×5100 mm, the SC - 660 is suitable for large - scale site layout. The SC - 660 applies intelligent control, optimized crushing chamber design and energy - saving technologies, improving its safety, crushing efficiency and energy utilization rate, and providing reliable crushing support for large - scale mining and building material production projects.
