Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | DHKS4230 |
| Feed opening | 1060×750 mm |
| Max feed size | 640 mm |
| CSS Range | 65 - 200 mm |
| Capacity(by hour) | 90 - 310 tph |
| Motor power | 110 KW |
*Note: The processing capacity of the DHKS4230 jaw crusher may vary with different materials and feeding sizes.
Seen from the picture the monitoring system can clearly monitor every corner of the stone production line. It is part of our whole automatic stone production line.
In this 200tph production line in Tengchong Yunnan it can produce 121305 stone and has a good selling in construction market especially 13 stone.
This 600tph production line basically configured with PCZ1615 heavy hammer crusher ZG1538 feeder 3YKZ2670 vibrating screen*2 sets，PC1213 hammer crusher 2YKZ2670 vibrating screen*2 sets.
For applications requiring significant processing power, the DHKS4230 Jaw Crusher is a powerful solution. This model comes with a 1060×750 mm feed opening, capable of processing materials up to 640 mm. The adjustable discharge opening ranges from 65 to 200 mm, providing versatility in achieving the desired product size. With a capacity range of 90 to 310 t/h and powered by a 110 kW motor, the DHKS4230 delivers outstanding performance for large-scale operations.
Application: Ideal for large-scale mining operations, construction projects, and industrial processing plants.
Structure: The DHKS4230 is built with a robust frame and advanced structural design to ensure high capacity and efficiency while being easy to maintain.
Large processing capacity and high efficiency.
Uniform particle size and reduced flaky stone content.
Easy access for maintenance and component replacement.
