Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | HD72 - 57 |
| Feed opening | 460 x 720 mm |
| Max feed size | 425 mm |
| CSS Range | 45 - 100 mm |
| Capacity(by hour) | 50 - 120 tph |
| Motor power | 55 KW |
| Dimensions | 1566 x 1965 x 1630 mm |
*Note: The processing capacity of the HD72 - 57 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity230 - 450 tph
Max. feed size750 mm
Motor power132 KW
Live Chat
Nominal capacity110 - 330 tph
Max. feed size630 mm
Motor power110 KW
Live Chat
Several belt conveyors are conveying the materials to different directions. All the belt conveyors are customized by our professional engineers. Each production process matches well with each other.
The pics show actual production site. This stone production line is close to the mining area which reduces a lot of transport cost and increases the overall profit of the operator.
As an economical and reasonable stone production line it only requires a few sets of equipment in order to finish the production of final material with high rate of return so there is new customer engaged in stone production.
The HD72 (57) German Version Jaw Crusher is a medium-sized unit, allowing a maximum feed size of 425mm, with a processing capacity of 40-120 tons per hour. Its discharge opening adjustment range is 45-100mm, powered by a 6-pole 55kW motor, and the dimensions are 1566mm x 1965mm x 1630mm. This equipment integrates energy-saving, environmental protection, and high productivity, suitable for coarse crushing of medium-hardness materials. Key features include:
Better Carrying Capacity: The HD series jaw crusher uses two super bearings to support the moving jaw, providing better carrying capacity and stable wear resistance.
Optimized Structure: Research staff optimized the overall structure and balanced part weights, using precise calculations to determine the structure of the flywheel and pulley and the weight of the counterweight, effectively reducing equipment vibration levels, making the equipment run more stably and reliably.
High Crushing Efficiency and Low Cost: The manganese steel alloy jaw plates have increased thickness, are strong and durable, and their symmetrical design allows for secondary usage, effectively improving crushing efficiency and reducing costs.
