Product data

modelJC1200
Feed opening1200 x 1100 mm
Max feed size1000 mm
CSS Range100 - 250 mm
Capacity(by hour)245 - 755 tph
Motor power160 kW
Weight41,000 kg
Rotation speed of eccentric shaft220 rpm

*Note: The processing capacity of the JC1200 jaw crusher may vary with different materials and feeding sizes.

Request a quoteMobiles tracked brochure

Our range jaw crushers

JC771 jaw crusher

JC771 jaw crusherJC771

Nominal capacity590-180 tph

Max. feed size

Motor power315-400 KW

Live Chat
JC2200 jaw crusher

JC2200 jaw crusherJC2200

Nominal capacity750 - 1595 tph

Max. feed size1200 mm

Motor power400 kW

Live Chat
JC1150 jaw crusher

JC1150 jaw crusherJC1150

Nominal capacity115 - 500 tph

Max. feed size630 mm

Motor power110 kW

Live Chat

Case stories

200TPH Stone Plant in Laibin Guangxi

The owner of this production line has over 20 years of experience in the construction of stone plan. By compared with many others it selects Dingli’s equipment since the aggregates produced have sound grain shape better quality.

300TPH River Pebble Crusher Plant in Chongqing

Relying on local river pebble resource the customer invests such a 300tph stone crushing line. Our KPC1313 hard rock crusher adopts the rotor with two rows of hammers so it can fully crush the materials. Hydraulic cylinder pulls the the s

1500TPH Aggregates Production Line in Huaiyuan Bengbu

There are hammer crushers placed side by side in the opposite direction. The raw materials and unqualified materials are conveyed into crushers through transmission pipeline for fine material shape. This production line is wholly designed b

Additional product information

JC1200 Jaw Crusher: High-Throughput Crushing for Abrasive Materials

Product Overview

The JC1200 jaw crusher is a high-throughput crushing machine designed to handle abrasive materials efficiently. Its innovative design maximizes the throughput and crushing ratio.

Technical Specifications

  • Feed Opening Length: 1200 mm
  • Feed Opening Width: 1100 mm
  • Maximum Feed Size: 1000 mm
  • Adjustable Discharge Opening Range: 100 - 250 mm
  • Shaft Speed: 220 rpm
  • Motor Power: 160 kW
  • Weight: 41,000 kg
  • Capacity: 245 - 755 t/h

Application Features

  • Deep V-Shaped Chamber: Optimizes feeding and throughput.
  • Hydraulic Wedge Adjustment: Enables easier and safer adjustment of the discharge opening.
  • Simplified Installation: Integrated motor base reduces space requirement and simplifies installation.

Key Advantages

  • Robust Construction: Heavy-duty moving jaw assembly with high-quality cast steel and large, forged eccentric shaft ensures reliability.
  • Reduced Maintenance: Replaceable cheek plates protect the moving jaw from wear, reducing maintenance costs.
  • Smooth Operation: Optimized crushing angle ensures efficient crushing and smooth passage of material.
