Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | PEW200 x 1300 |
| Feed opening | 200 x 1300 mm |
| Max feed size | ≤ 180 mm |
| CSS Range | 10 - 30 mm |
| Capacity(by hour) | 12 - 35 tph |
| Motor power | 30 - 37 KW |
| Dimensions | 1320 x 2150 x 1175 mm |
| Weight | 7500 Kg |
| Rotation speed of eccentric shaft | 320 |
*Note: The processing capacity of the PEW200 x 1300 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity15 - 50 tph
Max. feed size≤ 220 mm
Motor power30 - 37 KW
Live Chat
Nominal capacity15 - 70 tph
Max. feed size≤ 350 mm
Motor power37 - 45 KW
Live Chat
On the basis of local materials of limestone our technicians elaborately inspected the field for the best place and built this Sichuan production line with convenient resource places production and transportations.
As a 600tph fine gravel production line in Mangao Huishui Guizhou it can produce about 1000 ton finished stone which is mainly configured with ZG1550 vibrating feeder PCZ1615 heavy hammer crusher*2 ZSJ1218 dual sand shaping machine.
Dingli does not make specific equipment configuration until survey of production site for many times and comprehensive knowledge of the material to be crushed.
With a feed opening size of 200×1300mm, this model can process materials up to 180mm in size. Running at 320 rpm, the PEW200×1300 handles capacities between 12 and 35 tons per hour. Weighing around 7,500 kg, it includes a hydraulic oil station and lubrication system suitable for automated processes.
High-Quality Components: Uses FEA technology, featuring a moving jaw assembly made from high-quality cast steel and a heavy-duty eccentric shaft manufactured from forgings.
Enhanced Structural Integrity: The integral cast steel bearing housing ensures perfect alignment with the frame, increasing radial strength and overall robustness.
Simplified Adjustment: The discharge opening is adjusted using a hydraulic wedge mechanism, making adjustments straightforward and secure.
Maintenance Efficiency: Centralized lubrication system makes maintenance tasks more convenient.
Optimal Crushing Performance: The V-shaped crushing chamber maintains consistent feed size and enhances crushing efficiency.
Overload Protection: Elbow plates break when non-crushable materials enter the crushing chamber, safeguarding critical parts. Hydraulic cylinders provide overload protection by releasing hydraulic oil during overloads.
