Home>Specifications and models>Sand making machine
Request a quote

Technical Specifications

ModelDVSI75
Rotor Diameter730 mm28.74 inch
Maximum Feed Size35 mm1.38 inch
Capacity100-180 mtph110-199 stph
Power200 kW272 HP
Rotor Speed1740R/Min
Weight9.7 t21384 lbs
Overall Dimension4180×2180×2690 mm164.57×85.83×105.91 inch

*Note: The processing capacity of the DVSI75 cone crusher may vary with different materials and feeding sizes.
