Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderHorizontal Vibrating Screen
| Model | Screen mesh layers | Screen specifications (mm) | Feeding size (mm) | Angle (°) | Amplitude (mm) | Vibration frequency (r/min) | Motor power (kw) | Capacity (t/h) | Weight (t) | External dimensions (mm) |
| 2NTH1848 | 2 | 1930 × 4900 | 250 | 0 | 16 - 19 | 730 - 875 | 22 | 11 - 30 | 7.8 | 5575 × 3121 × 1520 |
| 3NTH1848 | 3 | 30 | 9.3 | 5575 × 3121 × 1980 |
*Note: The processing capacity of the NTH1848 Vibrating Screens may vary with different materials and feeding sizes.
Airplane Construction in Liu Panshui Guizhou chose 300tph aggregates production line. From the picture we get to know it chooses four mineral equipment of PCZ1512 heavy hammer crusher vibrating feeder and two efficient vibrating screens.
This production line has improved a lot in the aspect of operation scale and environmental protection compared with many other small traditional production lines in the local place.
The 200t/h stone production line configuration is PCZ1510 heavy hammer crusher ZG0938 vibrating feeder 2YK1560 vibrating screen*2 sets.
