Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderHorizontal Vibrating Screen
| Model | Screen mesh layers | Screen specifications (mm) | Feeding size (mm) | Angle (°) | Amplitude (mm) | Vibration frequency (r/min) | Motor power (kw) | Capacity (t/h) | Weight (t) | External dimensions (mm) |
| 2NTV2560 | 2 | 2540 × 6100 | 250 | 0 - 10 | 16 - 19 | 730 - 875 | 37 | 9 - 26 | 11.6 | 6775 × 3820 × 1650 |
| 3NTV2560 | 3 | 16.5 | 6775 × 3820 × 2125 |
*Note: The processing capacity of the NTV2560 Vibrating Screens may vary with different materials and feeding sizes.
Seen from the pics the whole stone crushing line adopts fully-closed mode. Compared with previously open-pit operation it is more eco-friendly. The feed silo production process and discharge silo are also enclosed by the closing plate to
1200TPH aggregates production machines were all installed on the foundation that ensure it has a clean production. And with substantial steel structure it has longer service life by few operation wear condition. Xinxiang Dingli hammer crus
The owner of this production line has over 20 years of experience in the construction of stone plan. By compared with many others it selects Dingli’s equipment since the aggregates produced have sound grain shape better quality.
