Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Model | Dynamic cone speed (rpm) | Eccentricity(mm) | Motor power(kW) | Equipment weight(kg) | Cavity | Feeding Size(mm) | Tight Side Discharge Port (mm) Corresponding Production Capacity (t/h) | ||||||||||||
| 6 | 8 | 10 | 13 | 16 | 19 | 22 | 25 | 29 | 32 | 35 | 38 | 41 | |||||||
| CC200 | 360 | 16-36 | 160 | 12600 | EC | 185 | 113 | 157 | 169 | 179 | 191 | 207 | 218 | 230 | 218 | 174 | |||
| C | 145 | 138 | 149 | 160 | 170 | 182 | 196 | 207 | 197 | 156 | 120 | ||||||||
| MC | 115 | 60 | 147 | 158 | 170 | 182 | 193 | 168 | 152 | 123 | |||||||||
| M | 90 | 88 | 138 | 149 | 160 | 170 | 161 | 137 | 109 | ||||||||||
| MF | 75 | 64 | 111 | 121 | 130 | 132 | 120 | 97 | |||||||||||
| F | 50 | 82 | 87 | 92 | 101 | 108 | 110 | 100 | 81 | ||||||||||
*Note: The processing capacity of the CC200 cone crusher may vary with different materials and feeding sizes.
Equipment configuration: PCZ1615 heavy hammer crusher ZGC1538 vibrating feeder 3YKZ3070 vibrating screen*2 sets. Performance feature: low investment cost high interests and high automation.
This 600tph production line basically configured with PCZ1615 heavy hammer crusher ZG1538 feeder 3YKZ2670 vibrating screen*2 sets，PC1213 hammer crusher 2YKZ2670 vibrating screen*2 sets.
In this production line we firstly crushed the huge materials into smaller ones by crusher and then crushed into smaller finished stones by second crushing; lastly we need a sand maker to produce quality sand.
The CC200 is a remarkable piece of equipment in the realm of material crushing, designed to meet diverse industrial needs.
Dynamic Cone Speed: Runs at 360 rpm, ensuring a good balance between processing speed and quality of crushed materials.
Adjustable Eccentricity: Ranges from 16 to 36 mm, providing flexibility to handle different types of materials and achieve desired output sizes.
Motor Power: Equipped with a 160 - kW motor, which supplies sufficient power for efficient crushing operations.
Equipment Weight: Weighs 12,600 kg, offering stability during the crushing process to minimize vibrations and ensure accurate performance.
Once powered on, the motor starts rotating the dynamic cone. The adjustable eccentricity determines how the materials are drawn into the crushing chamber. Here, the layer - pressure crushing principle comes into play. The materials are subjected to compressive forces and gradually broken down until they are small enough to be discharged from the crusher.
It finds its place in industries like mining and construction. In mining, it helps in processing ores effectively. In construction, it plays a role in producing aggregates for building structures and infrastructure. Its adaptability makes it a valuable asset across various projects.
In conclusion, the CC200 single - cylinder cone crusher, with its unique combination of features and reliable working mechanism, serves as an efficient solution for material crushing in multiple industrial settings.
