Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Cavity Type | XCP200 (Medium Crushing) | XCP200 (Fine Crushing) | ||||
| A | B | A | B | C | D | |
| Feed Opening (mm) | 330 | 250 | 220 | 150 | 80 | 40 |
| Maximum Feed Size (mm) | 280 | 210 | 180 | 120 | 60 | 32 |
| Minimum Discharge Opening (mm) | 27 | 25 | 18 | 15 | 9 | 6 |
| Maximum Discharge Opening (mm) | 65 | 60 | 35 | 35 | 35 | 35 |
| Processing Capacity (t/h) | 160 - 370 | 65 - 210 | ||||
| Motor Power (kW) | 110 - 160 | |||||
| Main Unit Weight (kg) | 10,600 | |||||
*Note: The processing capacity of the XGP200 cone crusher may vary with different materials and feeding sizes.
Its seen from the pics that with large feed opening the hammer crusher can hold a large quantity of material for once. The protective device can prevent the materials from spillover which improves the capacity of entire production line.
Machine configuration: ZG1550 vibrating feeder + PCZ1615 heavy hammer crusher + 3YKQ2470 vibrating screen*2 + XPC1216 hammer crusher + 4YKQ2670 vibrating screen*2 + XS3016 bucket wheel sand washer*2
It is seen the stone production line is next to concrete production ba
The XGP200 Single Cylinder Hydraulic Cone Crusher operates on the principle of layer compression crushing. The material is fed into the crushing chamber where it is subjected to high pressure between the moving and fixed cones. This process efficiently reduces the size of the material while minimizing fines and maximizing the quality of the final product.
Large-Scale Sand and Gravel Plants
Mining Operations
Coal Mining
Construction Materials Production
