Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Model | GYS 400 | |||||
| Cavity Type | C1 | C2 | C3 | F1 | F2 | F3 |
| Max Feed Size (mm) | 190 | 168 | 110 | 85 | 70 | 50 |
| Min Discharge Size (mm) | 19 | 16 | 13 | 8 | 6 | 3 |
| Discharge Opening Adjustment Range (mm) | 19-51 | 16-38 | 13-31 | 8-25 | 6-16 | 3-16 |
| Capacity (t/h) | 207-400 | 162-350 | 126-310 | 109-230 | 82-230 | 40-230 |
| Motor Power (kW) | 200 | |||||
| Weight (t) | 20 | |||||
*Note: The processing capacity of the GYS400 cone crusher may vary with different materials and feeding sizes.
In this production line we firstly crushed the huge materials into smaller ones by crusher and then crushed into smaller finished stones by second crushing; lastly we need a sand maker to produce quality sand.
Investment advantage: compared with jaw and impact crusher it saves not only equipment investment but also large space & manpower. It is featured by small investment and fast recovery of cost.
As to the process of cement production you should firstly crush the materials of limestone and clay and then matching.
GYS 400 Multi-Cylinder Hydraulic Cone Crusher: Operating Principles and Performance
The GYS 400 Multi-Cylinder Hydraulic Cone Crusher operates on the principle of layered compression, where particles are crushed through mutual compression. This method ensures a higher proportion of cubic-shaped products and reduces the number of needle-like and flaky stones, resulting in a more uniform particle size distribution. The machine's high-speed and stroke combination significantly increases its crushing capacity and efficiency.
The GYS 400 is designed to handle large volumes of material with high efficiency. The single hydraulic cylinder provides precise control over the discharge opening, ensuring optimal performance. The machine's ability to produce a high proportion of cubic-shaped products and reduce needle-like and flaky stones results in a more uniform particle size distribution.
The GYS 400 features an advanced sealing system that prevents dust and contaminants from entering the internal components, extending the machine's lifespan. The modular design and easy access to internal parts make maintenance quick and straightforward, minimizing downtime and reducing operating costs.
