Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Model | Cavity Type | Max Feed Size (mm) | Minimum Discharge Size (mm) | Processing Capacity (t/h) | Motor Power (kW) | Machine Weight (t) |
|---|---|---|---|---|---|---|
| HP315 | C | 13 | 290 | 190-610 | 26 | 315 |
| F | 6 | 100 | 108-320 |
*Note: The processing capacity of the HP315 cone crusher may vary with different materials and feeding sizes.
The coal gangue sand production line can process coal gangue into sand aggregate, which can not only solve environmental pollution, but also make up for the shortage of sand aggregate resources. It is an economic and environmental protection resource utilization mode, which meets the strategic requirements of green sustainable development.
This production line of 1100 tons of sand and aggregate can achieve unified production management, unmanned shovel loading, unmanned inspection, unmanned dust collection, and the use of one-click start-stop operations.
Upon this situation we upgraded our design with the process of first crushing desilt crushing shaping crushing and then sand making. And we can adjust discharge size with market demand with low soil and average finished material.
In industries such as mining, building materials, and metallurgy, the material crushing process is a crucial link, and the performance of the crusher directly affects production efficiency and product quality. The HP315 hydraulic cone crusher, with its unique design and excellent performance, has become a powerful tool for processing various materials with medium and above - medium hardness.
The HP315 is equipped with two cavity types, the C - cavity and the F - cavity, which can precisely meet the diverse requirements for material particle sizes according to different production scenarios.
The C - cavity excels in coarse and medium - sized crushing operations. With a maximum feed size of 290mm and a minimum discharge size of 13mm, in mining scenarios, for large - sized ores such as iron ore and copper ore, the C - cavity can quickly crush them into particle sizes suitable for subsequent processing. Its processing capacity is 190 - 610 tons per hour, and this high - efficiency processing capacity ensures the efficient operation of mining production, greatly improving the mining efficiency.
The F - cavity focuses on fine - crushing tasks. With a maximum feed size of 100mm and a minimum discharge size of 6mm, in the fine - processing of building materials, such as the production of high - quality construction aggregates, the F - cavity can precisely crush raw materials to particle sizes that meet strict quality standards, ensuring the excellent quality of building materials. Its processing capacity is 108 - 320 tons per hour, balancing fineness and production efficiency to meet the demand for high - quality raw materials in the construction industry.
