SCS200

SCS200 Cone Crusher: Exceptional Crushing Solutions

The SCS200 cone crusher is a highly efficient and versatile piece of equipment that plays a significant role in the industrial crushing sector. With its carefully designed features and reliable performance, it caters to a wide range of applications, meeting the diverse needs of various industries.

I. Diverse Cavity Types and Their Specifications

The SCS200 comes equipped with four distinct cavity types, namely EC, C, M, and F. Each of these cavity types is engineered with specific characteristics that determine its functionality and suitability for different crushing tasks.

For the EC cavity, the discharge opening range is set at 185 mm, while the minimum discharge opening size varies from 13 to 38 mm. This unique combination allows it to handle materials in a way that can achieve the desired output particle sizes for specific production requirements. The C cavity, with a discharge opening range of 145 mm and a minimum discharge opening size also within the range of 13 to 38 mm, offers consistent and efficient crushing performance, adapting well to a variety of material inputs.

Moving on to the M cavity, it has a discharge opening range of 90 mm and a minimum discharge opening size ranging from 10 to 32 mm. This setup makes it particularly suitable for applications where a finer crushing result is preferred. The F cavity, on the other hand, features a discharge opening range of 50 mm and a minimum discharge opening size between 6 and 25 mm. It is designed to deliver even more precise and fine crushing, catering to those industrial processes that demand strict control over the particle size of the output materials.

II. Variable Processing Capacity

Another key aspect of the SCS200 is its variable processing capacity, which varies depending on the selected cavity type. The EC cavity can handle a processing capacity within the range of 69 to 208 tons per hour. This wide range enables it to adapt to different production scales, whether it's for smaller batches or larger volume processing. The C cavity has a processing capacity ranging from 66 to 150 tons per hour, providing flexibility in meeting specific production targets.

The M cavity is capable of processing materials at a rate between 64 and 104 tons per hour, ensuring efficient crushing for applications that require a more controlled output volume. Meanwhile, the F cavity can manage a processing capacity within the range of 48 to 77 tons per hour, offering a suitable option for those operations where precision and a relatively lower throughput are key considerations.

III. Power and Weight Specifications

To drive its crushing operations effectively, the SCS200 is powered by a motor with a maximum installed power of 132 kw. This power level is carefully calibrated to ensure that the crusher can operate smoothly and handle the materials with the necessary force while maintaining energy efficiency. In terms of weight, excluding the motor, the crusher weighs 9.2 tons. This relatively compact weight makes it easier to install and position in different industrial settings, without sacrificing its stability during operation.

In summary, the SCS200 cone crusher combines its multiple cavity types, variable processing capacities, and appropriate power and weight specifications to offer a comprehensive and reliable solution for industrial crushing needs. It continues to prove its value in numerous applications across different industries, contributing to efficient and high-quality production processes.
