CJ2440

CJ2440 Jaw Crusher: Advanced Primary Crushing Solution

The CJ2440 jaw crusher represents the pinnacle of modern crushing technology, designed to provide users with a reliable and efficient primary crushing solution. Ideal for processing limestone, granite, and other materials with compressive strengths up to 280 MPa, this model offers improved productivity, ease of use, reduced environmental impact, and significant energy savings over conventional jaw crushers.

Technical Specifications

• Maximum Feed Size: 500 mm
• Production Capacity: 85 - 300 t/h
• Adjustable Discharge Opening: 60 - 175 mm
• Motor Power: 75 - 90 kW
• Weight: 15,600 kilograms

Key Features

• High-Quality Moving Jaw Assembly: The CJ2440 comes with a robust moving jaw component made from high-grade materials, ensuring better reliability and extending the machine's lifespan by around 3 to 5 years.
• Scientific Finite Element Analysis: Leveraging sophisticated finite element analysis methods, the CJ2440 optimizes the crushing process, increasing output by at least 1.5 times and significantly enhancing efficiency.
• Innovative Toothed Liner Design: The new toothed liner design adds 30% more effective length to the jaw plates, increasing the contact surface with materials and boosting crushing capacity.
• Wedge Block Discharge Adjustment Mechanism: The CJ2440 features a wedge block adjustment system for the discharge opening, resulting in a more uniform final product size and simplifying the adjustment procedure.
• Core Components: Key components include the stationary jaw, moving jaw, eccentric shaft, and frame. The moving jaw's bearing has superior sealing capabilities, ensuring reliable operation without oil leakage, which enhances the overall functionality of the equipment.
