Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | CJ443 |
| Feed opening | 850 x 1100 mm |
| CSS Range | 80 - 215 mm |
| Capacity(by hour) | 170 - 625 tph |
| Motor power | 132 - 160 kW |
*Note: The processing capacity of the CJ443 jaw crusher may vary with different materials and feeding sizes.
It is seen on the production site the crushed limestone is uniformly conveyed into the silo. The hammer crusher is configured as primary crushing equipment for this stone crusher plant. With sound grain size and shape the crushed sand and
With large quantity of soil in raw material it is suitable to adopt the feeder functioned with screening which can greatly reduce the impurities in production and improve the material cleanness; moreover the customer satisfaction can also be improved.
On the basis of local materials of limestone our technicians elaborately inspected the field for the best place and built this Sichuan production line with convenient resource places production and transportations.
The CJ443 Jaw Crusher features a feed opening of 850 x 1100 mm, discharge range of 80 - 215 mm, and a capacity of 170 - 625 tons per hour, powered by a 132 - 160 kW motor. The CJ443 Jaw Crusher excels with its solid construction, superior chamber design, and durable moving jaw assembly, performing admirably in multiple sectors such as mining, smelting, building materials, and others.
The CJ443 Jaw Crusher features a symmetrical “V” shaped chamber design, large incline angle of toggle plate, large stroke, and reasonable rotational speed, resulting in larger feed sizes, higher output, more uniform particle size, and reduced wear on the jaws. The heavy-duty moving jaw assembly uses forged heavy eccentric shafts, heavy-duty rolling bearings, and a moving jaw body optimized via finite element analysis, ensuring high impact resistance and stability.
The CJ443 Jaw Crusher uses mechanical or hydraulic discharge adjustment mechanisms. The double wedge block adjustment system is simpler, safer, and faster compared to shim adjustment, saving downtime. Specialized rubber dampening devices secure the crusher, effectively absorbing vibration peaks while allowing vertical and longitudinal displacement, thereby reducing the impact on the foundation.
