Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | CJ5149 |
| Feed opening | 1050 x 1250 mm |
| CSS Range | 160 - 300 mm |
| Capacity(by hour) | 350 - 900 tph |
| Motor power | 132 - 160 kW |
*Note: The processing capacity of the CJ5149 jaw crusher may vary with different materials and feeding sizes.
This a complete crushing and screening plant for construction aggregate production including crushed stone and artificial sand. The output is 350 ton per hour and raw material is limestone. Please see the pics for its layout and equipment configured
With the special terrain of wide limestone distribution it has been Xinxiang Dingli Mining Equipment Industry main market.
In the production site it can be seen that with a relatively high degree of automation the production line almost does not need too much manpower and the discharge size can also be adjusted with relatively high crushing efficiency.
The CJ5149 Jaw Crusher features a feed opening of 1050 x 1250 mm, discharge range of 160 - 300 mm, and a capacity of 350 - 900 tons per hour, powered by a 132 - 160 kW motor. The CJ5149 Jaw Crusher excels with its solid construction, superior chamber design, and durable moving jaw assembly, performing admirably in multiple sectors such as mining, smelting, building materials, and others.
The CJ5149 Jaw Crusher features a symmetrical “V” shaped chamber design, large incline angle of toggle plate, large stroke, and reasonable rotational speed, resulting in larger feed sizes, higher output, more uniform particle size, and reduced wear on the jaws. The heavy-duty moving jaw assembly uses forged heavy eccentric shafts, heavy-duty rolling bearings, and a moving jaw body optimized via finite element analysis, ensuring high impact resistance and stability.
The CJ5149 Jaw Crusher uses mechanical or hydraulic discharge adjustment mechanisms. The double wedge block adjustment system is simpler, safer, and faster compared to shim adjustment, saving downtime. Specialized rubber dampening devices secure the crusher, effectively absorbing vibration peaks while allowing vertical and longitudinal displacement, thereby reducing the impact on the foundation.
