Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | CSZ116 |
| Feed opening | 1150 x 760 mm |
| CSS Range | 70 - 200 mm |
| Capacity(by hour) | 165 - 520 tph |
| Motor power | 132 kW |
| Weight | 21,500 kg |
| Rotation speed of eccentric shaft | 260 rpm |
*Note: The processing capacity of the CSZ116 jaw crusher may vary with different materials and feeding sizes.
Work Process The large rocks are fed by the vibrating feeder into PCZ1512 heavy hammer crusher in a uniform manner. The crushed stones are then conveyed by the conveyor to 2YKZ2460 vibrating screen for classifying the stone materials in various sizes
Our companys technical staffs according to the customers request develop the entire production line of stone production process and select the required types of equipment and its supporting parts.
This 1,000 tons of aggregate production line was put into operation in September 2018, using DLPCZ1820 heavy hammer crusher, DLPC1220 plastic hammer crusher, DL3YKZ3070 vibrating screen and other sets of mine production equipment, the introduction of a complete set of mine intelligent management system.
The CSZ116 Jaw Crusher is a rugged piece of machinery designed to stand the test of time. Perfect for use in quarries, mines, and other industrial settings, the CSZ116 combines robustness with efficiency. Its modular frame design ensures that the unit can withstand the strains of continuous use, making it a smart investment for any business looking to enhance its crushing capabilities.
Equipped with a powerful 132 kW motor spinning at 260 rpm, the CSZ116 delivers impressive performance. The unit's weight of 18600 kg and its working load of 21500 kg attest to its strength and durability. The feed opening of 1150 x 760 mm is ample enough to accommodate a variety of material sizes, ensuring that the CSZ116 can handle diverse processing tasks. Output capacities range from 165 to 520 tons per hour, depending on the discharge setting.
The CSZ116 is designed with the user in mind. The modular frame not only enhances its structural integrity but also makes it easier to perform routine maintenance and upgrades. The adjustable discharge setting allows for customization based on specific application requirements, ensuring that the machine can be optimized for different materials and output sizes.
