Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | CSZ130 |
| Feed opening | 1300 x 1000 mm |
| CSS Range | 100 - 250 mm |
| Capacity(by hour) | 270 - 831 tph |
| Motor power | 160 kW |
| Weight | 44,000 kg |
| Rotation speed of eccentric shaft | 220 rpm |
*Note: The processing capacity of the CSZ130 jaw crusher may vary with different materials and feeding sizes.
Machine configuration: ZG1550 vibrating feeder + PCZ1615 heavy hammer crusher + 3YKQ2470 vibrating screen*2 + XPC1216 hammer crusher + 4YKQ2670 vibrating screen*2 + XS3016 bucket wheel sand washer*2
It is seen at the production site that the stone with large diameter is entering into the crusher through the feed opening. As for the material with the particle size not exceeding 1.6m we adopt the crusher with large hourly capacity.
This is a crushing production line established by cement industry that can crush not only limestone but clay and gypsum with high efficiency full crushing and lower wear-resistance.
The CSZ130 Jaw Crusher represents the pinnacle of crushing technology, designed to meet the demands of the most challenging industrial applications. From sand and gravel production to mining and coal extraction, the CSZ130 is a versatile tool that can handle a wide range of materials with ease. Its modular frame design ensures long-lasting durability and easy maintenance, making it a valuable addition to any processing line.
Driven by a powerful 160 kW motor spinning at 220 rpm, the CSZ130 is capable of producing impressive output volumes. The unit itself weighs 40100 kg and can operate under a working load of 44000 kg. The feed opening dimensions of 1300 x 1000 mm allow for a substantial intake of material, ensuring that the machine can handle large volumes efficiently. Output ranges from 270 to 831 tons per hour, depending on the discharge setting.
The CSZ130 is designed with the user in mind. Its modular structure not only enhances its durability but also makes it easy to maintain and service. The ability to adjust the discharge opening to suit specific needs means that the CSZ130 can be adapted to a variety of tasks, making it a versatile tool for any industrial setting.
