Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw Crusher
| model | HJC130 |
| Feed opening | 1100 x 1300 mm |
| Max feed size | 950 mm |
| CSS Range | 160 - 280 mm |
| Capacity(by hour) | 400 - 800 t/h |
| Motor power | 185 kW |
*Note: The processing capacity of the HJC130 jaw crusher may vary with different materials and feeding sizes.
This 1400tph production line is configured with 3 sets of vibrating screen running side by side the efficiency of which is 50% higher than that of combined screening of two screens.
This stone crushing plant is upgrading into an eco-friendly production line after 6-year using.
As a 600tph fine gravel production line in Mangao Huishui Guizhou it can produce about 1000 ton finished stone which is mainly configured with ZG1550 vibrating feeder PCZ1615 heavy hammer crusher*2 ZSJ1218 dual sand shaping machine.
The HJC130 Jaw Crusher is a flagship model in the HJC Series Jaw Crushers, known for its superior crushing capacity and flexible adjustment capabilities. This crusher can handle a maximum feed size of 950 mm, making it suitable for primary crushing of ultra-large rock and extremely hard ore materials.
The HJC130 Jaw Crusher features an inlet size of 1100 x 1300 mm, capable of accepting a wide range of material inputs, enhancing operational flexibility. The adjustable outlet range of 160 - 280 mm provides users with precise control options to ensure the final product meets specific application requirements.
This crusher has a production capacity of 400 - 800 t/h, suitable for ultra-large-scale operations. Equipped with a 185 kW motor, it ensures efficient power output while considering energy efficiency, achieving both economic and environmental goals.
In terms of design, the HJC130 Jaw Crusher features a heavy-duty moving jaw assembly including high-quality cast steel components, a heavy eccentric shaft, four large self-aligning roller bearings, and a labyrinth seal structure. These components work together to ensure reliable operation under extreme conditions.
Additionally, the vibration damping installation design effectively absorbs peak loads from equipment vibrations, reducing noise pollution and minimizing impact on the foundation, thus extending the equipment's service life.
