Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | JC150 |
| Feed opening | 1400 x 1200 mm |
| CSS Range | 125 -250 mm |
| Capacity(by hour) | 780-1025 tph |
| Motor power | 200 KW |
| Weight | 51,200 kg |
| Rotation speed of eccentric shaft | 220 r/min |
*Note: The processing capacity of the JC150 jaw crusher may vary with different materials and feeding sizes.
In this production line we firstly crushed the huge materials into smaller ones by crusher and then crushed into smaller finished stones by second crushing; lastly we need a sand maker to produce quality sand.
As a large medium stone production line Xinxiang Dingli finally the design and configuration plan of 800t/h production line after combining local circumstance and material characteristics and all around inspection and research.
This production line added water to reduce powder pollution and have a green production environment.
The JC150 Jaw Crusher is a reliable machine designed for primary crushing operations. With a feed opening of 1400×1200 mm, this model can handle materials up to 960 mm in size. The crusher is powered by a 200 kW motor and operates at a speed of 220 rpm. Weighing 51,200 kg, the JC150 offers a wide range of capacities depending on the discharge setting.
High Throughput: Can produce from 405 to 1025 tons per hour, depending on the discharge setting.
Sturdy Construction: Crafted with durable materials to ensure longevity and minimal wear.
Flexible Adjustment: The discharge setting can be easily adjusted to meet different product size requirements.
Energy Efficiency: Optimized design reduces energy consumption while maintaining high productivity.
User-Friendly Controls: Simple operation and maintenance requirements mean less training and lower labor costs.
Safety Protocols: Integrated safety measures protect operators and equipment during operation.
