Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | JC549II |
| Feed opening | 1250×1000 mm |
| Max feed size | 800 mm |
| CSS Range | 160-300 mm |
| Capacity(by hour) | 480-1105 tph |
| Motor power | 160-200 KW |
| Weight | 51,306 kg |
*Note: The processing capacity of the JC549II jaw crusher may vary with different materials and feeding sizes.
Nominal capacity12 - 35 tph
Max. feed size150 mm
Motor power30 kW
Live Chat
Its seen the two 2000tph gravel aggregates production lines are configured in an orderly manner. The finished materials with various grain sizes are discharged from corresponding outlet and then transported away by the trucks. The automatic
Completed in : 2018-01 Designed by : Xinxiang Dingli Mining Equipment Co. Ltd. Background : Such 3000tph aggregate production line is built through integration of previous six small aggregate production lines. Design feature : The belt conveyor syst
Seen from the pics the whole stone crushing line adopts fully-closed mode. Compared with previously open-pit operation it is more eco-friendly. The feed silo production process and discharge silo are also enclosed by the closing plate to
The JC549II jaw crusher is designed for advanced crushing technology in high-volume applications, capable of handling materials up to 800mm in size through a 1250×1000mm feed opening. The adjustable discharge gap ranges from 160 to 300mm, achieving a throughput of 480 to 1105 tons per hour. Equipped with a motor delivering 160 to 200 kW of power, the JC549II is a powerful machine with significant dimensions.
The JC549II is designed for ease of use and automation, incorporating features such as an integrated control panel and remote monitoring capabilities. Operators can adjust the machine’s settings and monitor its performance from a distance, streamlining operations and reducing the need for manual intervention. This advanced technology makes the JC549II a highly efficient and user-friendly choice for large-scale industrial projects.
