Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | JC663 |
| Feed opening | 1600×1200 mm |
| Max feed size | 1000 mm |
| CSS Range | 150-350 mm |
| Capacity(by hour) | 520-1475 tph |
| Motor power | 250-355 KW |
| Weight | 90,789 kg |
*Note: The processing capacity of the JC663 jaw crusher may vary with different materials and feeding sizes.
Completed in : 2018-01 Designed by : Xinxiang Dingli Mining Equipment Co. Ltd. Background : Such 3000tph aggregate production line is built through integration of previous six small aggregate production lines. Design feature : The belt conveyor syst
This a complete crushing and screening plant for construction aggregate production including crushed stone and artificial sand. The output is 350 ton per hour and raw material is limestone. Please see the pics for its layout and equipment configured
Machine: ZGC1538 vibrating feeder + PCZ1615 heavy hammer crusher + 4*YKZ2460 vibrating screen + ZSJ 1218 dual rotor sand maker
The JC663 jaw crusher is designed for high-throughput processing in large-scale operations, capable of handling materials up to 1000mm in size through a 1600×1200mm feed opening. The adjustable discharge gap ranges from 150 to 350mm, achieving a throughput of 520 to 1475 tons per hour. Driven by a motor delivering 250 to 355 kW of power, the JC663 is a powerful solution for extensive operations.
Safety and Maintenance:
Regular maintenance and inspection are critical for ensuring the JC663 operates at peak efficiency. Common issues like overheating bearings or excessive vibration can be addressed promptly through scheduled maintenance routines. By keeping the machine well-maintained, operators can minimize downtime and extend the life of the equipment. The JC663 also incorporates safety features such as overheat protection and emergency stop mechanisms, ensuring a safer working environment.
