Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | PE900 x 1060 |
| Feed opening | 900 x 1060 mm |
| Max feed size | 685 mm |
| CSS Range | 230 - 290 mm |
| Capacity(by hour) | 230 - 390 tph |
| Motor power | 110 KW |
| Dimensions | 2870 x 2420 x 2940 mm |
| Weight | 33 t |
| Rotation speed of eccentric shaft | 250 r/min |
*Note: The processing capacity of the PE900 x 1060 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity16 - 64 tph
Max. feed size340 mm
Motor power30 KW
Live Chat
Nominal capacity1 - 3 tph
Max. feed size125 mm
Motor power5.5 KW
Live Chat
Nominal capacity2 - 6 tph
Max. feed size180 mm
Motor power7.5 KW
Live Chat
This production line added water to reduce powder pollution and have a green production environment.
Relying on local river pebble resource the customer invests such a 300tph stone crushing line. Our KPC1313 hard rock crusher adopts the rotor with two rows of hammers so it can fully crush the materials. Hydraulic cylinder pulls the the s
Tiancheng Mining and Zhongyu cooperation, the new production of 1500 tons of environmental protection intelligent aggregate production line, production line by Zhongyu design, provide and install a complete set of mining equipment and intelligent management system
Maintenance:Regular maintenance of the PE 900×1060 jaw crusher includes checking the wear of the jaw plates, lubricating moving parts, and cleaning the machine. Proper maintenance ensures the longevity and optimal performance of the crusher. Routine inspections and timely replacement of worn parts can prevent unexpected downtime and ensure consistent productivity.
Technical Parameters:
Feed Opening Size (mm): 900×1060
Maximum Feed Size (mm): 685
Discharge Opening Adjustment Range (mm): 230-290
Capacity (t/h): 230-390
Eccentric Shaft Speed (r/min): 250
Motor Power (kw): 8P 110
Dimensions (L×W×H) (mm): 2870×2420×2940
Total Weight (t): 33
Working Principle:The periodic reciprocating motion of the movable jaw relative to the fixed jaw causes the material to enter the crushing cavity when the jaws separate and to be crushed through compression, bending, and splitting when the jaws come together.
