Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | PE900 x 1200 |
| Feed opening | 900 x 1200 mm |
| Max feed size | 750 mm |
| CSS Range | 100 - 200 mm |
| Capacity(by hour) | 220 - 380 tph |
| Motor power | 110 KW |
| Dimensions | 3470 x 2876 x 3330 mm |
| Weight | 52 t |
| Rotation speed of eccentric shaft | 208 r/min |
*Note: The processing capacity of the PE900 x 1200 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity40 - 110 tph
Max. feed size425 mm
Motor power55 KW
Live Chat
Nominal capacity150 - 336 tph
Max. feed size650 mm
Motor power110 KW
Live Chat
Nominal capacity130 - 330 tph
Max. feed size640 mm
Motor power110 KW
Live Chat
The gravel aggregates production line is connected by the belt conveyor for directly transporting the aggregates to the concrete production project. With configuration of the complete set of gravel production equipment the crushing line ca
It is seen at the production site that the stone with large diameter is entering into the crusher through the feed opening. As for the material with the particle size not exceeding 1.6m we adopt the crusher with large hourly capacity.
At the production site it is seen that by adopting the crusher with hourly capacity of 1200 ton the production process is greatly simplified compared with previous production lines configured with more than one crusher.
Introduction:The PE 900×1200 jaw crusher is a robust and efficient machine designed for primary crushing applications. It is ideal for processing hard and abrasive materials in industries such as mining, construction, and quarrying.
Technical Parameters:
Model: PE 900×1200
Feed Opening Size (mm): 900×1200
Maximum Feed Size (mm): 750
Discharge Opening Adjustment Range (mm): 100-200
Capacity (t/h): 220-380
Eccentric Shaft Speed (r/min): 208
Motor Power (kw): 8P 110
Dimensions (L×W×H) (mm): 3470×2876×3330
Total Weight (t): 52
| Closed side setting (mm) | Capacity (t/h) |
|---|---|
| 100 | 156.7 |
| 120 | 197.4 |
| 140 | 238 |
| 160 | 278.7 |
| 180 | 319.4 |
| 200 | 360 |
