Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | PE800 x 1060 |
| Feed opening | 800 x 1060 mm |
| Max feed size | 640 mm |
| CSS Range | 130 - 190 mm |
| Capacity(by hour) | 130 - 330 tph |
| Motor power | 110 KW |
| Dimensions | 2710 x 2430 x 2800 mm |
| Weight | 29.8 t |
| Rotation speed of eccentric shaft | 250 r/min |
*Note: The processing capacity of the PE800 x 1060 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity5 - 21 tph
Max. feed size210 mm
Motor power15 KW
Live ChatNominal capacity130 - 330 tph
Max. feed size640 mm
Motor power110 KW
Live Chat
Nominal capacity3 - 10 tph
Max. feed size180 mm
Motor power11 KW
Live Chat
In aggregates production line hammer crusher works as primary crusher that can crush bulk limestone.
Its seen the two 2000tph gravel aggregates production lines are configured in an orderly manner. The finished materials with various grain sizes are discharged from corresponding outlet and then transported away by the trucks. The automatic
The gravel aggregates production line is connected by the belt conveyor for directly transporting the aggregates to the concrete production project. With configuration of the complete set of gravel production equipment the crushing line ca
Jaw crushers are indispensable for primary crushing in various crushing, sand-making, grinding, and mineral processing lines. The PE 800×1060 jaw crusher stands out due to its strong production capacity, wide applicability, and excellent crushing performance. This model is suitable for processing a variety of ores with compressive strengths not exceeding 320 MPa, such as granite, limestone, river pebbles, etc. Below are the technical parameters of the PE 800×1060 jaw crusher:
Technical Parameters:
Feed Opening Size (mm): 800×1060
Maximum Feed Size (mm): 640
Discharge Opening Adjustment Range (mm): 130-190
Capacity (t/h): 130-330
Eccentric Shaft Speed (r/min): 250
Motor Power (kw): 8P 110
Dimensions (L×W×H) (mm): 2710×2430×2800
Total Weight (t): 29.8
| Closed side setting (mm) | Capacity (t/h) |
|---|---|
| 100 | 140 |
| 110 | 158 |
| 120 | 176 |
| 140 | 212 |
| 150 | 229 |
| 160 | 247 |
