Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | PE200 x 350 |
| Feed opening | 200 x 350 mm |
| Max feed size | 180 mm |
| CSS Range | 18 - 60 mm |
| Capacity(by hour) | 3 - 10 tph |
| Motor power | 11 KW |
| Dimensions | 1000 x 914 x 1112 mm |
| Weight | 1.5 t |
| Rotation speed of eccentric shaft | 276 r/min |
*Note: The processing capacity of the PE200 x 350 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity50 - 160 tph
Max. feed size500 mm
Motor power55 KW
Live Chat
Nominal capacity130 - 330 tph
Max. feed size640 mm
Motor power110 KW
Live Chat
Nominal capacity230 - 390 tph
Max. feed size685 mm
Motor power110 KW
Live Chat
On the production site we equipped our equipment on the cement ba
The project is under EPC general contract construction of Zhongyu and Denli, and tailor-made production line scheme for customers.
Its seen from the pics that with large feed opening the hammer crusher can hold a large quantity of material for once. The protective device can prevent the materials from spillover which improves the capacity of entire production line.
Technical Specifications:
Feed Opening Size (mm): 200×350
Maximum Feed Size (mm): 180
Discharge Opening Adjustment Range (mm): 18-60
Capacity (t/h): 3-10
Eccentric Shaft Speed (r/min): 276
Motor Power (kw): 4P 11
Dimensions (L×W×H) (mm): 1000×914×1112
Total Weight (t): 1.5
Description:The PE200×350 model extends the capabilities of the previous model by offering a slightly wider feed opening and increased throughput. This flexibility makes it ideal for applications where a higher volume of material needs to be processed without compromising on the quality of the end product. The adjustable discharge setting ensures that the output can be tailored to meet the requirements of different projects. Built for reliability and ease of maintenance, this crusher is a solid investment for mid-range crushing needs.
