Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | PEW1100 |
| Feed opening | 1100×1200 mm |
| Max feed size | ≤930 mm |
| CSS Range | 150-275 mm |
| Capacity(by hour) | 300-650 tph |
| Motor power | 185～200 KW |
| Dimensions | 4140×2660×3560 mm |
| Weight | 59200 Kg |
| Rotation speed of eccentric shaft | 210 |
*Note: The processing capacity of the PEW1100 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity15 - 50 tph
Max. feed size≤ 220 mm
Motor power30 - 37 KW
Live Chat
Nominal capacity15 - 70 tph
Max. feed size≤ 350 mm
Motor power37 - 45 KW
Live Chat
Its seen the crushing equipment is neatly arranged at the customers production site and the dust proof facility is installed in all the conveying equipment. The dust prevention measure is especially required in the junction of equipment.
It is seen the stone production line is next to concrete production ba
In aggregates production line hammer crusher works as primary crusher that can crush bulk limestone.
This model boasts a feed opening size of 1100×1200mm and can handle materials up to 930mm in size. Operating at a speed of 210 rpm, the PEW1100 can manage capacities ranging from 300 to 650 tons per hour. Weighing approximately 59,200 kg, it comes with a hydraulic oil station and lubrication system designed for automated production environments.
Robust Construction: Utilizes FEA technology, with a moving jaw assembly made of high-quality cast steel and a heavy-duty eccentric shaft crafted from forgings.
Increased Strength: The integral cast steel bearing housing provides optimal alignment with the frame, enhancing radial strength and overall durability.
Adjustment Ease: The discharge opening is adjusted using a hydraulic wedge mechanism, ensuring easy and rapid adjustments.
User-Friendly Maintenance: A centralized lubrication system facilitates easier maintenance.
Optimized Crushing: The V-shaped crushing chamber guarantees consistent feed size and improved crushing efficiency.
Protection Against Overload: Elbow plates break to protect components from damage due to non-crushable materials entering the crushing chamber. Hydraulic cylinders offer overload protection by releasing hydraulic oil during overload conditions.
