Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw Crusher
| model | PEW1311 |
| Feed opening | 1300 x 1130 mm |
| Max feed size | 1070 mm |
| CSS Range | 150 - 300 mm |
| Capacity(by hour) | 330 - 960 tph |
| Motor power | 160 kW |
| Dimensions | 3762 x 2468 x 3843 mm |
*Note: The processing capacity of the PEW1311 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity15 - 70 tph
Max. feed size≤ 350 mm
Motor power37 - 45 KW
Live Chat
Nominal capacity15 - 50 tph
Max. feed size≤ 220 mm
Motor power30 - 37 KW
Live Chat
This 600t/h production line has the basic configuration of PCZ1615 heavy hammer crusher PC1213 hammer crusher ZG1538 feeder 3YKZ2670 vibrating screen*2 sets 2YKZ2670 vibrating screen*2 sets.
The raw materials can be exploited in the place near production site which saves a lot of transport cost. All the equipment manufactured by us can right meet the requirements of the customer. With reasonable configuration such production
The pics show actual site of the production line which adopts fully-closed structure. Since little powder is produced in the process such eco-friendly stone production line has been widely promoted across China.
The PEW1311 European Type Jaw Crusher is a machine with powerful crushing capability suitable for various complex conditions. It has a feed opening of 1300 x 1130mm, capable of handling a maximum feed particle size of 1070mm. The adjustable discharge setting ranges from 125 to 300mm, with a capacity of 330 to 960 tons per hour. The unit is equipped with a 160kW motor and measures 3762 x 2468 x 3843mm. The PEW1311’s monolithic cast steel structure enhances the stability of the equipment, keeping it in good condition during prolonged operation.
The monolithic cast steel structure of the PEW1311 reduces unnecessary burdens on the frame compared to traditional two-piece bearing housings, enhancing overall stability and reliability.
