Product data

SpecificationDetails
Nominal capacity70 - 172 mtph77 - 190 stph
Max. feed size267.0 mm10.5 in.
Motor power90 kW121 hp
Closed side setting (CSS) range13.0 - 35.0 mm0.5 - 1.4 in.
Eccentric throw range16.0 - 25.0 mm0.6 - 1.0 in.
Mantles (inner liners)A, B
Concaves (outer liners)EC, C
No of chambers2
Weight7,188 kg15,850 lb
Automation (ASRi)Optional
Lubrication tankStandard
Offline lubrication filtration unitOptional


The chambers available are:


CS440-NOMINAL CAPACITY*(MTPH)



ConcaveECC
Max. feed size (mm)F90177148
F100167223
Max. motor power (kW)90
Eccentric tdrow (mm)
16-2516-25
CSS (mm)13-70

16-76-105

1996-11282-113

22103-14287-120

25109-15193-128

29118-163100-117

32125-172106

35131-153-
Mantle
A/BA/B

*Note: The processing capacity of the CS420 cone crusher may vary with different materials and feeding sizes.

Request a quoteMobiles tracked brochure

Our range cone crushers

CS110D Cone Crusher

CS110D Cone CrusherCS110D

Nominal capacity50 - 181 t/h

Max. feed size

Motor power110 kW

Live Chat
CH420 Cone Crusher

CH420 Cone CrusherCH420

Nominal capacity23 - 135 mtph (25 - 149 stph)

Max. feed size155.0 mm (6.1 in.)

Motor power90 kW (121 hp)

Live Chat
CS75B Cone Crusher

CS75B Cone CrusherCS75B

Nominal capacity45 - 163 t/h

Max. feed size

Motor power75 kW

Live Chat

Case stories

200-250TPH Sand Making System of Zoomlion in Anyang

In the production site sand making system has feeding belt and discharging belt with crushing material of 1-2 1-3 0-5 types and granolithic and producing high quality sand.

500TPH Stone Crushing Plant in Shaoyang Hunan

The raw materials can be exploited in the place near production site which saves a lot of transport cost. All the equipment manufactured by us can right meet the requirements of the customer. With reasonable configuration such production

200TPH Aggregates Production Line in Tengchong Yunnan

In this 200tph production line in Tengchong Yunnan it can produce 121305 stone and has a good selling in construction market especially 13 stone.

Additional product information

Stationary Cone Crushers 400 - 600 Series - CH420

Stationary Cone Crushers 400 - 600 Series - CH420

General Information

The CH420 cone crusher is equipped with a hydraulically supported main shaft that is supported at both ends, ensuring stable operation.

Key Features

  • Hydroset™ system: Offers safety and setting - adjustment functions, enhancing the crusher's overall operation and adaptability.
  • ASRi™: Automatically adjusts the crusher to feed conditions, optimizing performance and productivity.
  • Unibody mainframe: Guarantees optimal strength and reduces maintenance, minimizing downtime and costs.
  • Lifting from above: Reduces risks and enables safer maintenance procedures, creating a safer working environment.
  • Excellent versatility: With a wide range of chambers having different feed acceptance, it can handle diverse materials and production needs.
