Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Model | DLDH440 | ||
| Cavity Type | H1 (Fine) | H2 (Medium-Fine) | H3 (Ultra-Fine) |
| Feed Opening | 240 mm | 140 mm | 70 mm |
| Max Feed Size | ≤ 190 mm | ≤ 110 mm | ≤ 55 mm |
| CSS Range | ≤ 16 mm | ≤ 13 mm | ≤ 9 mm |
| Capacity (by hour) | 116 - 396 t/h | 97 - 346 t/h | 90 - 251 t/h |
| Motor Power | 250 kW | ||
*Note: The processing capacity of the DLDH440 cone crusher may vary with different materials and feeding sizes.
Two 2500-3000tph production lines enter into operation at the same time. In order to ensure both the quality and capacity we configure two sets of PCZ2125 heavy hammer impact crusher for primary crushing 4 sets of shaping hammer crusher a
This stone crushing plant is upgrading into an eco-friendly production line after 6-year using.
Equipment configuration: PCZ1615 heavy hammer crusher ZGC1550 vibrating feeder 2YK2460 vibrating screen*2 sets Performance feature: high production line output good products quality compressive strength and seamless stone.
The DLDH440 Multi-Cylinder Hydraulic Cone Crusher is a high-performance machine designed for fine and medium-fine crushing applications. It is well-suited for processing materials like iron ore, basalt, and limestone. With a motor power of 250kW, the DLDH440 can handle capacities ranging from 116 to 396 tons per hour, making it a powerful choice for large-scale operations.
Advanced Crushing Technology: Ensures the production of high-quality, cubic-shaped products.
Efficient Transmission System: The spiral bevel gear transmission system provides smooth and quiet operation.
Overload Protection: Safeguards the hydraulic system, ensuring long-term reliability.
Dust Prevention Mechanism: The U-T dust seal system and positive pressure dust prevention device keep the lubrication system clean.
Intelligent Control System: Offers multiple operating modes and real-time monitoring, ensuring optimal performance and timely maintenance.
