E-SMG300S

E-SMG300S Single Cylinder Hydraulic Cone Crusher: Powerful Engine for Large-scale Production

E-SMG300S single cylinder hydraulic cone crusher, as a high-end product of Shanghai Sanme Co., Ltd., integrates top-notch mechanical, hydraulic, electrical, automation and intelligent control technologies. It is carefully designed for large-scale mining and massive aggregate production and has unique and excellent performance in the industry, being a key equipment for efficient, stable and precise crushing operations.

Analysis of Technical Parameters

1. Power and Cavity Type

This crusher model is equipped with a powerful 250KW power and has three well-designed cavity types: EC, C and M. The EC cavity type can have a maximum feed size of 450mm, which enables it to easily handle huge ore blocks mined from large-scale mines and shows unparalleled advantages in the primary crushing stage. The C cavity type with a maximum feed size of 400mm can operate stably and efficiently in the intermediate crushing stage, further crushing the material to an appropriate particle size range. The M cavity type with a maximum feed size of 300mm focuses on fine crushing operations with strict requirements for product particle size, ensuring the uniformity and high quality of the final product.

2. Closed-side Discharge Port and Production Capacity

From the data of the closed-side discharge port and the corresponding production capacity, in the EC cavity type, when the discharge port is 29mm, the production capacity has already reached 267t/h. As the discharge port gradually increases to 90mm, the production capacity can soar to 365 - 456t/h. There are also excellent production capacity performances in the C and M cavity types. For example, in the C cavity type, when the discharge port is 32mm, the production capacity is 239 - 299t/h, and the production capacity also increases correspondingly with the increase of the discharge port. This indicates that the equipment can not only handle large-size materials but also achieve extremely high production capacity while ensuring product quality. Operators can flexibly adjust the size of the closed-side discharge port according to specific production requirements, thus precisely controlling the production capacity and product particle size to meet different production tasks and market demands.

Application Advantages

1. High-efficiency Crushing Performance

With its optimized cavity design, the E-SMG300S can perfectly realize laminated crushing under the condition of choked feeding. This crushing method has a very significant effect on improving crushing efficiency and improving product shape. Whether processing hard granite or medium-hard limestone, a large amount of material can be crushed into the required particle size in a short time, reducing the production cycle and improving the overall production efficiency. For example, in large-scale building aggregate production, it can quickly crush the original stone into high-quality aggregate to meet the needs of large-scale construction projects.

2. Low Operation Cost

The advanced hydraulic adjustment of the discharge port technology makes the adjustment during the operation of the equipment extremely convenient. The size of the discharge port can be adjusted in a timely and accurate manner to ensure that the crusher always operates in the best working state of choked feeding. This not only greatly reduces the wear rate of wearing parts and prolongs the service life of wearing parts but also effectively reduces the operation cost. Compared with traditional crushers, in the long run, it can save a large amount of maintenance and replacement costs for enterprises and improve the economic benefits of enterprises.

3. Flexible Conversion of Crushing Modes

Due to the unity of its main body structure, by simply replacing the liner, the E-SMG300S can easily obtain different crushing cavity types to meet various process requirements of coarse and fine crushing. This flexibility enables the equipment to adapt to the production needs of different stages in large-scale mining. In the initial stage of mining, the EC cavity type can be used for coarse crushing operations. With the deepening of mining and the change of product particle size requirements, it can be quickly replaced with the C or M cavity type for intermediate or fine crushing operations without replacing the entire equipment, which greatly improves the versatility and resource utilization rate of the equipment and reduces the equipment investment cost.

4. Convenient Operation and Maintenance

The high-quality hydraulic technology endows the E-SMG300S with simple operation and convenient maintenance characteristics. On the one hand, it can effectively realize the overload protection function. When encountering unexpected overload situations, the equipment can automatically stop or adjust to avoid damage to key components and ensure the safe and stable operation of the equipment. On the other hand, the simplified crusher structure and reduced weight design make all maintenance and inspection work can be easily completed from the upper part of the crusher. Operators do not need to perform complex disassembly and lifting operations, which greatly shortens the maintenance time, reduces the downtime of the equipment, improves the continuity of production and creates more production value for enterprises.

5. Advantage of Large Feed Opening Design

The S model of the E-SMG300S adopts an ultra-large feed opening design. For example, the EC cavity type has a maximum feed size of 450mm. This unique design enables it to seamlessly connect and cooperate efficiently with the front coarse crushing equipment (such as large jaw crushers), significantly improving the processing capacity of the entire crushing system. When processing large ores or river pebbles and other materials, its large feed opening can smoothly accept oversized materials, reducing the环节 and cost of material pretreatment. Moreover, in some specific production scenarios, it can even replace the jaw crusher as a coarse crushing device, further expanding the application range and usage scenarios of the equipment and providing more production process options and flexibility for enterprises.

In conclusion, the E-SMG300S single cylinder hydraulic cone crusher, with its excellent performance and numerous application advantages, occupies a crucial position in large-scale mining and massive aggregate production fields. It is an ideal choice for enterprises to achieve efficient production, reduce costs and improve product quality and will strongly promote the development and progress of the industry.
