Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Model | Motor Power (kW) | Chamber Type | Closed side Feeding Port (mm) | Open side Feeding Port (mm) | Minimum Discharge Port (mm) | Production Capacity (t/h) Open circuit, Closed side Discharge Port (mm) | ||||||||
| 10 | 12 | 15 | 20 | 25 | 32 | 40 | 45 | 52 | ||||||
| B - SMS4000 | 315 | EC | 299 | 333 | 30 | 140 - 175 | 180 - 220 | 220 - 280 | 260 - 320 | 295 - 370 | 325 - 430 | 370 - 500 | 410 - 560 | 465 - 630 |
| C | 252 | 292 | 25 | |||||||||||
| M | 198 | 245 | 20 | |||||||||||
| F | 111 | 164 | 15 | |||||||||||
| DC | 92 | 143 | 10 | |||||||||||
| DM | 52 | 107 | 8 | |||||||||||
| DF | 40 | 104 | 6 | |||||||||||
*Note: The processing capacity of the E-SMS4000 cone crusher may vary with different materials and feeding sizes.
Our large-capacity hammer crusher can hold the stone material with maximum size of 2m. No secondary crusher is configured for the production of final products which greatly simplifies the process.
The project is an expansion project, the crushing raw material is limestone, the production capacity is required to be 800-1500 tons, and the finished material is used for construction.
In the production site of customer it can be seen that the raw materials of sand making are mainly the stones with large grain size and through being crushed these stones are finally used for sand making.
In the mining and construction industries, the B - SMS4000 crusher is chosen by many enterprises for its outstanding performance. The following will introduce its working principle.
The B - SMS4000 crusher adopts advanced hydraulic cone crushing technology. Its core is that the motor drives and transmits power to the internal eccentric sleeve, which in turn drives the crushing cone to swing. When materials enter the crushing chamber from the feed inlet, the crushing cone squeezes and grinds the materials under the precise control of the hydraulic system.
This squeezing and grinding action is achieved through the relative movement between the crushing cone and the bowl liner. The materials in the crushing chamber will be subjected to repeated crushing forces multiple times, gradually breaking large pieces into small pieces. The hydraulic system plays a crucial role in this process. It not only can provide stable power for the crushing cone but also can automatically adjust the swing amplitude and frequency of the crushing cone according to the hardness and feed amount of the materials.
For example, when encountering high - hardness materials, the hydraulic system will increase the crushing force of the crushing cone to ensure that the materials can be effectively crushed. And when the feed amount is large, the system can also adjust flexibly to prevent the equipment from being damaged due to overload while ensuring high production efficiency.
The working principle of the B - SMS4000 crusher enables it to adapt to various materials with different hardness and particle sizes, and produce uniformly - sized and regularly - shaped products under the premise of ensuring production volume, providing high - quality raw materials for subsequent production processes.
