Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Model | Cavity Type | Max feed size | Maximum Motor Installation Power | Throughput under Closed side Discharge Opening (CSS) (t/h) | |||||||
| (mm) | (kW) | 44 | 48 | 51 | 54 | 60 | 64 | 70 | 76 | ||
| GPY800S | Ultra coarse | 670 | 600 | 1050-1200 | 1250-1310 | 1320-1420 | 1450-1530 | 1550-1650 | 1675-1750 | 1830-1900 | 1925-2000 |
*Note: The processing capacity of the GPY800S cone crusher may vary with different materials and feeding sizes.
This stone crushing plant is upgrading into an eco-friendly production line after 6-year using.
Although there are only several sets of mining equipment adopted in this production line the capacity can reach 300 ton per hour. It mainly lies in Dingli’s PCZ 1512 heavy hammer crusher with the hourly capacity of 320 ton.
Our companys technical staffs according to the customers request develop the entire production line of stone production process and select the required types of equipment and its supporting parts.
In the highly competitive current of the mining and building material processing industries, the high efficiency, stability and precision of crushing equipment are extremely crucial for enterprises to enhance productivity and product quality. The GPY800S ultra-coarse crushing cone crusher stands out with its excellent performance in the ultra-coarse crushing process and promotes the development of the industry.
The GPY800S has a maximum installed power of 600KW and is capable of handling high-hardness ores and super-large pieces of materials. Its maximum feeding size is 670mm, and granite blocks from open-pit mines or dense iron ores from deep mines can smoothly enter the well-designed crushing chamber.
Based on the crushing mechanics principle, the GPY800S, with its unique crushing cone motion trajectory and chamber design, enables the materials in the chamber to fully experience squeezing, impact and grinding. When the closed-side setting (CSS) is set to 76mm, the hourly output is stably between 1925 and 2000 tons. This production capacity far exceeds that of similar equipment and meets the large-scale production needs of large mining enterprises.
In a large iron mine with a daily processing capacity of tens of thousands of tons, the GPY800S, as the core equipment in the ultra-coarse crushing stage, can crush large iron ore blocks into a size suitable for subsequent fine grinding by ball mills, improve the efficiency of the beneficiation process, reduce the unit production cost, and contribute to the efficient operation and profitability of the enterprise.
