Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderCone Crusher
| Model | HPM400 | ||||
| Cavity Type | C1 | C2 | C3 | F1 | F2 |
| Max Feed Size (mm) | 299 | 198 | 111 | 92 | 52 |
| Min Discharge Size (mm) | 240 | 160 | 90 | 75 | 40 |
| Capacity (t/h) | 270 - 630 | 243 - 630 | 210 - 630 | 162 - 370 | 126 - 370 |
| Motor Power (kW) | 315 | ||||
| Weight (t) | 27 | ||||
*Note: The processing capacity of the HPM400 cone crusher may vary with different materials and feeding sizes.
The above picture shows the production site of 1000tph aggregates production line of Tongxingyuan Building Material Company. The aligned belt conveyors are transporting aggregates in an orderly manner. The pulse bag filter independently dev
This production line added water to reduce powder pollution and have a green production environment.
The two production lines can be independent to meet the production needs of off-peak season. The screening and powder selection links adopt highly compact building design to reduce the floor area. The sand washing link has water recycling design to reduce the waste of water resources and reduce the production cost.
HPM400 Multi-Cylinder Hydraulic Cone Crusher: High Capacity and Advanced Technology
The HPM400 Multi-Cylinder Hydraulic Cone Crusher is a high-capacity machine designed for the most demanding crushing applications. With a maximum feed opening size of 1400 mm and a processing capacity range of 270 - 630 t/h, the HPM400 is perfect for processing hard materials like granite, basalt, and quartz.
The HPM400 utilizes an advanced layered compression principle, which significantly enhances crushing efficiency by leveraging the mutual compression of particles. This method results in a higher yield of cubic-shaped products with a more uniform particle size distribution, improving the overall quality of the output.
The liners of the HPM400 are made from ultra-high alloy manganese steel (ZGMn18Cr2), ensuring a long service life and minimal wear. The bolted liner structure allows for easy and quick replacement, reducing maintenance time and costs.
The HPM400 features a protective mechanism that smoothly releases impact forces, protecting the machine from damage caused by over-iron passage. Once the over-iron material passes through, the discharge opening automatically returns to its original position, ensuring continuous and safe operation.
The HPM400 is equipped with a Siemens PLC control system, enabling automated production and real-time monitoring. This intelligent control system optimizes performance, ensures consistent product quality, and minimizes downtime.
