HSC100 Single Cylinder Hydraulic Cone Crusher: An Overview

The HSC100 single cylinder hydraulic cone crusher is an optimized and high-performance crusher with a single-cylinder structure. It is widely applied in industries such as mining, building materials, and metallurgy. It can perform medium and fine crushing operations on various ores and rocks like granite, limestone, river pebbles, basalt, and iron ore.

It finds its use in many fields including sand and gravel yards, mine exploitation, concrete mixing stations, and dry mortar production, dealing with materials like granite, diabase, basalt, river pebbles, limestone, dolomite, metal ores, and non-metal ores.

1. Performance Features

Firstly, with a reasonable eccentric amount, swing frequency, and a special crushing cavity design, this crusher achieves a larger crushing ratio, higher output, and better particle shape. The well-designed parameters ensure that the materials are crushed effectively to meet different production requirements.

Secondly, it combines the functions of discharge port adjustment and overload protection into one. The streamlined structure makes it convenient to use. Operators can easily adjust the discharge port according to the actual needs and don't have to worry about equipment damage caused by overloads.

Moreover, the intelligent control system enables real-time monitoring of the equipment's operating status. Based on the monitoring data, timely adjustments can be made to keep the equipment in an ideal operating state all the time. This intelligent feature greatly improves the overall efficiency and stability of the production process.

Finally, the reinforced equipment structure and the advanced overload protection system jointly guarantee the long-term and safe operation of the crusher. It can withstand the rigors of continuous operation in harsh industrial environments.

2. Working Principle

When the HSC100 single cylinder hydraulic cone crusher is working, the electric motor drives the horizontal transmission shaft to rotate through a V-belt. Then, the horizontal transmission shaft drives the eccentric sleeve to rotate via bevel gears. Under the urging of the eccentric sleeve, the movable cone part makes a gyratory motion. Once the materials enter the crushing cavity, they are continuously impacted and squeezed between the crushing wall and the concave, and thus get crushed. After being crushed, the materials are discharged from the lower part.

3. Specifications of HSC100

3.1 Cavity Types

It has five cavity types, namely S1, S2, H1, H2, and H3. Each cavity type is designed to handle different feed sizes and produce specific output particle sizes, catering to diverse production needs.

3.2 Maximum Feed Size and Minimum Discharge Opening

For the S1 cavity, the maximum feed size is 240 mm and the minimum discharge opening is 22 mm. For the S2 cavity, the maximum feed size is 200 mm and the minimum discharge opening is 19 mm. The H1 cavity has a maximum feed size of 135 mm and a minimum discharge opening of 10 mm. The H2 cavity features a maximum feed size of 65 mm and a minimum discharge opening of 8 mm. And for the H3 cavity, the maximum feed size is 35 mm and the minimum discharge opening is 4 mm.

3.3 Processing Capacity

The processing capacity varies among different cavity types. The S1 cavity has a processing capacity ranging from 85 - 170 t/h. The S2 cavity can process 70 - 130 t/h. The H1 cavity's processing capacity is 45 - 115 t/h. The H2 cavity can handle 35 - 80 t/h. And the H3 cavity has a processing capacity of 27 - 60 t/h.

3.4 Motor Power and Machine Dimension

Powered by a 90 kW motor, the HSC100 has sufficient power to drive the crushing process. Its machine dimension is 1550×1575×2545 mm, which indicates its physical size and helps in planning the installation space in the production site.

4. Conclusion

In conclusion, the HSC100 single cylinder hydraulic cone crusher combines excellent performance features, a reliable working principle, and specific specifications to offer a great solution for material crushing in various industries. It is a valuable piece of equipment that can contribute to improving production efficiency and product quality.
