Applications of the Small Capacity S75B Cone Crusher

Among various crushing equipments, the S75B small capacity cone crusher demonstrates irreplaceable value in multiple fields with its unique performance parameters, especially suitable for production scenarios with relatively small output demands but high requirements for product quality.

I. Small Mine Exploitation and Concentration

In the exploitation operations of some small mines, the S75B cone crusher has become an ideal choice. Its maximum feed particle size varies according to the chamber type, with 13mm for the F chamber, 33mm for the C chamber, and 51mm for the EC chamber, enabling it to handle relatively small-sized ore raw materials after primary crushing. For small mines, this feed capacity not only conforms to their exploitation scale and ore characteristics but also avoids resource waste and cost increase caused by oversized equipment.

Meanwhile, the minimum discharge opening size of this crusher can reach 3mm for the F and C chambers and 6mm for the EC chamber, allowing it to produce finished ore with smaller and uniform particle sizes, meeting the demands of small mines for high-quality concentrates. For example, in the exploitation of some small non-ferrous metal mines, such as copper, lead, and zinc mines, the ore crushed by the S75B has a finer particle size, which is beneficial for subsequent beneficiation processes such as flotation, improving the metal recovery rate and thus enhancing the economic benefits of the mine.

II. Architectural Decoration Stone Processing

In the architectural decoration stone industry, strict requirements are imposed on the particle size and shape of stones. The processing capacity of the S75B cone crusher is 27 - 90t/h for the F chamber, 27 - 100t/h for the C chamber, and 59 - 127t/h for the EC chamber, and this small output range is just suitable for the production and processing of some medium and high-end architectural decoration stones.

For commonly used decorative stones such as marble and granite, the S75B can crush them into particle sizes that meet architectural design requirements, used for manufacturing exquisite countertops, floor tiles, wall decorative panels, etc. Its small discharge opening size can ensure that the produced stone particles are round and the surface is smooth, improving the quality and aesthetics of the stone, meeting the high-quality requirements of high-end construction projects for decorative stones, and adding unique artistic charm to the building.

III. Production in Small Sand and Gravel Yards

In some small sand and gravel yards, the S75B cone crusher also plays an important role. Due to its moderate output, it can flexibly adjust the production plan according to market demands, avoiding the problem of product overstock caused by excessive output.

For the production of building sand and gravel, the S75B can produce various specifications of sand and gravel products according to different chamber types and discharge opening settings. For example, when preparing concrete sand, by precisely controlling the discharge opening size, medium and fine sands that meet national standards can be produced, meeting the demands of small construction projects for sand and gravel aggregates and providing reliable raw material guarantees for local infrastructure construction.

IV. Crushing and Pretreatment of Chemical Raw Materials

In the chemical industry, some raw materials need to be crushed to meet the requirements of subsequent chemical reactions or processing techniques. The small capacity characteristic of the S75B cone crusher enables it to accurately crush some chemical raw materials while ensuring the stability of the product particle size.

For example, for chemical raw materials such as limestone and gypsum, the S75B can crush them into suitable particle sizes for the production of chemical products such as cement and fertilizers. Its precise crushing ability helps improve the reaction efficiency and product quality of chemical raw materials, reduce production costs, and plays a key role in the front-end links of chemical production, laying a solid foundation for the efficient and stable production of chemical enterprises.

In conclusion, the S75B small capacity cone crusher, with its suitable feed particle size, fine discharge opening adjustment, and moderate processing capacity, has found its applications in multiple fields such as small mines, architectural decoration, sand and gravel yards, and the chemical industry, providing powerful equipment support for the high-quality development of these industries, meeting the demands of different industries for small capacity and high-quality crushed products, and showing broad market application prospects.
