Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw Crusher
| model | C80 |
| Feed opening | 520 x 800 mm |
| Max feed size | 420 mm |
| CSS Range | 60 - 150 mm |
| Capacity(by hour) | 80 - 290 t/h |
| Motor power | 75 kW |
| Dimensions | 2650 x 1540 x 1780 mm |
| Rotation speed of eccentric shaft | 350 r/min |
*Note: The processing capacity of the C80 jaw crusher may vary with different materials and feeding sizes.
Although there are only several sets of mining equipment adopted in this production line the capacity can reach 300 ton per hour. It mainly lies in Dingli’s PCZ 1512 heavy hammer crusher with the hourly capacity of 320 ton.
Our companys technical staffs according to the customers request develop the entire production line of stone production process and select the required types of equipment and its supporting parts.
The 1200tph large stone production line configured by us for Wuxue Hubei mainly adopts PCZ1820 heavy hammer crusher PCX1220 shaping hammer crusher several sets of efficient vibrating screens and auxiliary dedusting facilities.
The C80 Jaw Crusher is a compact and efficient crushing machine designed and manufactured by our company using advanced foreign technology. This European-style jaw crusher is specifically engineered to handle materials with a compressive strength below 320MPa. It is widely used in mining, construction materials, cement, metallurgy, road construction, and chemical industries, particularly for crushing medium-hardness materials like rocks and ores.
The C80 Jaw Crusher operates smoothly without vibration, ensuring stable and reliable performance. This feature minimizes wear and tear on the machine, extending its lifespan and reducing maintenance needs. The advanced design provides a reliable and efficient crushing solution for demanding applications.
The C80 Jaw Crusher features a frameless structure with high-strength wall plates and precision-machined pins, forming a robust chassis that enhances load-bearing capacity. The moving jaw assembly, pulleys, and flywheels are all made from high-quality cast steel or cast iron, providing exceptional durability. The use of high-strength forged eccentric shafts and premium bearings ensures outstanding reliability.
The C80 Jaw Crusher has an optimized chamber design with well-coordinated feed opening dimensions and chamber height. The ratio of the feed opening length to width is carefully tested to maximize material throughput and minimize clogging issues.
The discharge opening adjustment mechanism uses a dual-wedge structure, making it easy and reliable to adjust. This allows users to quickly and conveniently change the discharge opening size, reducing downtime and improving operational flexibility.
