Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | CJ106 |
| Feed opening | 1060×700 mm |
| Max feed size | 560 mm |
| CSS Range | 70-200 mm |
| Capacity(by hour) | 120-580 tph |
| Motor power | 110 KW |
*Note: The processing capacity of the CJ106 jaw crusher may vary with different materials and feeding sizes.
Tiancheng Mining and Zhongyu cooperation, the new production of 1500 tons of environmental protection intelligent aggregate production line, production line by Zhongyu design, provide and install a complete set of mining equipment and intelligent management system
In this production site all the equipment is orderly placed in there for different processes. And it can save the electric energy by using huge inertance of high place production line to convey materials to the relative process equipment.
Work Process The large limestones are first crushed by primary crusher of PCZ hammer type then the crushed stones are processed by two sets of 3YKZ2470 vibrating screen for classification of materials in various sizes. At last the curshed stone th
Technical Specifications:
Model: CJ106
Max. Feeding Size: 1060×700 mm
Range of Discharging Port: 70-200 mm
Handling Capacity: 120-580 TPH
Power: 110 KW
The CJ106 jaw crusher is an advanced model designed to offer superior performance and efficiency. It features improvements in motion parameters, structural design, and adjustment methods, setting it apart from traditional jaw crushers.
Robust Design: Connected via cylindrical pins and bolted together, the frame components overcome stress concentration issues.
Enhanced Motion Parameters: Efficient crushing occurs in the upper part of the chamber with a larger stroke and higher crushing ratio in the lower part.
Compact and Stable: Takes up less space and operates stably, suitable for both fixed and mobile crushing applications.
Ease of Maintenance: Detachable structure simplifies transportation and installation, especially useful for underground setups.
Longevity: Extended bearing life and standardized components reduce spare parts inventory.
Ideal for processing materials such as river pebbles, granite, basalt, iron ore, limestone, quartz, diabase, construction waste, iron ore, and gold.
