CJ5971

CJ5971 Jaw Crusher: Premier Primary Crushing System

The CJ5971 jaw crusher is a premier primary crushing system that combines the best in crushing technology with innovative design elements. Perfect for crushing limestone, granite, and materials with compressive strengths up to 280 MPa, the CJ5971 is acclaimed for its increased productivity, intuitive operation, lower environmental footprint, and significant energy savings over conventional jaw crushers.

Technical Specifications

• Maximum Feed Size: 1250 mm
• Production Capacity: 600 - 1800 t/h
• Adjustable Discharge Opening: 160 - 380 mm
• Motor Power: 335 - 400 kW
• Weight: 125,000 kilograms

Key Features

• High-Quality Moving Jaw Assembly: The CJ5971 is equipped with a durable moving jaw component made from high-grade materials, ensuring better reliability and extending the machine's lifespan by approximately 3 to 5 years.
• Scientific Finite Element Analysis: Employing advanced finite element analysis technologies, the CJ5971 optimizes the crushing process, increasing output by at least 1.5 times and substantially enhancing efficiency.
• Innovative Toothed Liner Design: The new toothed liner design adds 30% more effective length to the jaw plates, increasing the contact surface with materials and boosting crushing capacity.
• Wedge Block Discharge Adjustment Mechanism: The CJ5971 features a wedge block adjustment system for the discharge opening, leading to a more uniform final product size and simplifying the adjustment process.
• Core Components: Essential components include the stationary jaw, moving jaw, eccentric shaft, and frame. The moving jaw's bearing has superior sealing capabilities, ensuring reliable operation without oil leakage, which enhances the overall functionality of the equipment.
