Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | JCE1003 |
| Feed opening | 250× 1000 mm |
| Max feed size | 220 mm |
| CSS Range | 20 - 40 mm |
| Capacity(by hour) | 15- 50 tph |
| Motor power | 30 KW |
| Dimensions | 1400×1850×1310 mm |
| Rotation speed of eccentric shaft | 330 |
*Note: The processing capacity of the JCE1003 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity200- 500 tph
Max. feed size720 mm
Motor power132 KW
Live Chat
Nominal capacity125- 350 tph
Max. feed size650 mm
Motor power110 KW
Live Chat
This production line takes a leading role in the industry with relatively large hourly capacity. With the quality of crushed material meeting relative quality requirements of China such a line can provide qualified aggregates for highway railway.
Only configured with a heavy hammer crusher and four vibrating screens, this production line can produce six types of finished materials. Moreover the final products have sound grain shape
As a large limestone production province among China Jiangxi has been the major market of Xinxiang Zhongyu Dingli Mining Equipment Industry. We have built an 800-1000t/h stone production line for Pingxiang with our two hammer crusher.
The JCE1003 jaw crusher is designed for versatility and durability, capable of handling materials up to 220mm through a 250×1000mm feed opening. The adjustable discharge gap ranges from 20 to 40mm, catering to diverse processing needs. With an eccentric shaft rotation speed of 330 rpm, the JCE1003 can process between 15 and 50 tons of material per hour. Powered by a Y225M-6 motor with 30 kW of power at 980 rpm, the JCE1003 offers a compact and efficient solution with dimensions of 1400×1850×1310mm.
The JCE1003 is ideal for a variety of industries including metallurgy, mining, chemical processing, cement production, construction, refractory materials, and ceramics. This model excels in medium and fine crushing of various mid-hard ores and rocks with compressive strengths below 280MPa. Its ability to handle materials up to 220mm in size makes it suitable for a wide range of applications, ensuring consistent and high-quality output in diverse industrial settings.
