Product data

modelMC1250
Feed opening1250 x 950 mm
Max feed size950 mm
CSS Range100 - 250 mm
Capacity(by hour)240 - 750 tph
Motor power160 kW
Weight41,800 kg
Rotation speed of eccentric shaft220 rpm

*Note: The processing capacity of the MC1250 jaw crusher may vary with different materials and feeding sizes.

Request a quoteMobiles tracked brochure

Our range jaw crushers

MC1200 jaw crusher

MC1200 jaw crusherMC1200

Nominal capacity175 - 545 tph

Max. feed size870 mm

Motor power160 kW

Live Chat
MC800 jaw crusher

MC800 jaw crusherMC800

Nominal capacity55- 330 tph

Max. feed size

Motor power75 kW

Live Chat
MC1060 jaw crusher

MC1060 jaw crusherMC1060

Nominal capacity155 - 505 tph

Max. feed size700 mm

Motor power110 kW

Live Chat

Case stories

500TPH Stone Production Line in Hunan

Xinxiang Dingli is a professional mining equipment manufacturer engaged in production of crushing and screening equipment and configuration of the gravel production lines with various capacities.

300TPH Stone Production Line in Nanchang Jiangxi

This 300t/h production line basically configured with PCZ1512 heavy hammer crusher ZG1238 vibrating feeder 2YK1860 vibrating screen*3 sets.

1000TPH Cement Crushing Production Line

In this production sites we get to know all the crushing equipment was orderly installing by our professional technicians.

Additional product information

MC1250 Jaw Crusher: Modular Frame for Superior Performance

Technical Specifications

  • Feed Opening Width: 1250 mm
  • Feed Opening Depth: 950 mm
  • Power: 160 kW
  • Speed: 220 rpm
  • Weight: 41,800 kg
  • Capacity: 240-750 t/h
  • Product Size: Up to 620 mm (adjustable)

Key Features

  • Modular, Non-Welded Frame: High fatigue resistance and multiple installation options.
  • Precisely Balanced: Easy and economical installation.
  • Special Cast Steel Components: Durable and low operating costs.
  • Large Bearings: Four bearings of the same size for increased reliability.
  • Cast Steel Moving Jaws and Front/Back Walls: Strong and resilient design.
  • Double Wedge Adjustment System: Quick and safe adjustment of discharge opening.
  • Automated Lubrication: Ensures smooth operation.

Applications

  • Stone Crushing
  • Mining Operations
  • Recycling Concrete and Asphalt
  • Industrial Waste Processing

Performance Highlights

  • Optimal Crushing Chamber Design: Large stroke and high power ensure efficient crushing.
  • Customizable Toothed Plates and Side Liners: Adapt to various applications.
  • Controlled Feed Rate: Ensures uniform output and maximizes capacity.
