Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | PE870 x 1060 |
| Feed opening | 870 x 1060 mm |
| Max feed size | 660 mm |
| CSS Range | 200 - 260 mm |
| Capacity(by hour) | 190 - 336 tph |
| Motor power | 110 KW |
| Dimensions | 2810 x 2430 x 2800 mm |
| Weight | 31.5 t |
| Rotation speed of eccentric shaft | 250 r/min |
*Note: The processing capacity of the PE870 x 1060 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity500 - 1200 tph
Max. feed size1200 mm
Motor power280 - 380 KW
Live Chat
Nominal capacity130 - 330 tph
Max. feed size640 mm
Motor power110 KW
Live Chat
Nominal capacity16 - 64 tph
Max. feed size340 mm
Motor power30 KW
Live Chat
Leiming built a new-type gravel production line on the basis of prior stone production line for eco-friendly production.
Seen from the picture the monitoring system can clearly monitor every corner of the stone production line. It is part of our whole automatic stone production line.
Investment advantage: heavy hammer crusher replaces the traditional combination of jaw crusher and impact crusher. It is thus featured by small investment and fast recovery of cost.
The PE 870×1060 jaw crusher is designed for large-scale industrial applications and is renowned for its high-efficiency performance and wide applicability.
Technical Parameters:
Feed Opening Size (mm): 870×1060
Maximum Feed Size (mm): 660
Discharge Opening Adjustment Range (mm): 200-260
Capacity (t/h): 190-336
Eccentric Shaft Speed (r/min): 250
Motor Power (kw): 8P 110
Dimensions (L×W×H) (mm): 2810×2430×2800
Total Weight (t): 31.5
| Closed side setting (mm) | Capacity (t/h) |
|---|---|
| 200 | 339 |
| 210 | 358 |
| 220 | 377 |
| 230 | 396 |
| 240 | 415 |
| 250 | 434 |
| 260 | 453 |
