Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw crusher
| model | PEW180x1300 |
| Feed opening | 180 x 1300 mm |
| Max feed size | 150 mm |
| CSS Range | 10 - 30 mm |
| Capacity(by hour) | 12 - 35 t/h |
| Motor power | 30 kW |
| Dimensions | 1320 x 2150 x 1175 mm |
| Weight | 6,000 kg |
*Note: The processing capacity of the PEW180x1300 jaw crusher may vary with different materials and feeding sizes.
Nominal capacity12 - 35 tph
Max. feed size≤ 180 mm
Motor power30 - 37 KW
Live ChatNominal capacity12 - 35 t/h
Max. feed size150 mm
Motor power30 kW
Live Chat
Nominal capacity15 - 50 tph
Max. feed size≤ 220 mm
Motor power30 - 37 KW
Live Chat
From this site we get to know this production line builds with mountain that can make fully use of limestone. All the machines are installed and provided by Xinxiang Dingli with high matching.
The finished material is washed with water, the surface is clean, the perception is good, the quality is excellent, and the mud content is less, which can meet the market demand for high standard aggregate and machine-made sand, and greatly improve the economic efficiency.
It is seen at the production site that the stone with large diameter is entering into the crusher through the feed opening. As for the material with the particle size not exceeding 1.6m we adopt the crusher with large hourly capacity.
The PEW180x1300 jaw crusher is renowned for its efficiency in handling materials with compressive strengths up to 280 MPa, making it suitable for primary crushing tasks across industries such as metallurgy, mining, chemical engineering, cement production, construction, refractory materials, and ceramics.
Specifications
Structural Characteristics and Adjustment MechanismThe PEW180x1300 is characterized by its robust frame assembly, eccentric shaft transmission component, working chamber, safety devices, and discharge opening adjustment mechanism. The frame consists of side plates, front box components, and rear box weldments. The eccentric shaft drives the moving jaw, which crushes materials against the fixed jaw plate when the moving jaw advances. Safety features include a toggle plate, seat, spring, and spring pull rod, which protect the machine from damage under abnormal conditions. The adjustment mechanism allows for precise control over the discharge size, enhancing the flexibility and adaptability of the PEW180x1300 in various applications.
