CC100 Single - Cylinder Cone Crusher: An In-depth Look

The CC100 single - cylinder cone crusher is a remarkable piece of equipment that offers a combination of performance and functionality for various material crushing applications. It has unique features based on its specific design parameters.

1. Structure and Components

1.1 Dynamic Cone Assembly

The dynamic cone of the CC100 rotates at a speed of 395 rpm. This relatively high rotational speed enables the crusher to process materials at a good pace. The dynamic cone is precisely engineered to work in tandem with the other components of the crusher. It is built to withstand the forces generated during the crushing process and to ensure consistent and efficient contact with the materials being crushed. The fast rotation helps in quickly breaking down the incoming materials, making it suitable for applications where a relatively quick throughput is desired.

1.2 Eccentricity Adjustment Feature

With an eccentricity range of 13 - 28 mm, the CC100 offers flexibility in adjusting the crushing action. The eccentric mechanism, which might involve elements like the eccentric sleeve and related parts, allows for altering the movement path of the dynamic cone. This adjustability is crucial as it enables the crusher to adapt to different types of materials, whether they are softer or harder. For instance, a smaller eccentricity setting can be used for achieving a finer crushed product when dealing with materials that don't require excessive force, while a larger setting can be employed to handle more resistant materials and achieve a coarser crushing effect.

1.3 Motor and Power Transmission

Powered by a 90 - kW motor, the CC100 has sufficient power to drive the crushing operation. The motor is connected to the crusher's internal moving parts through a reliable power transmission system. This ensures that the energy from the motor is effectively transferred to the dynamic cone, enabling it to rotate and exert the necessary crushing force. The 90 - kW power is well-suited for handling a wide range of materials commonly encountered in industries like mining and construction.

1.4 Sturdy Frame and Weight Distribution

Weighing 7,200 kg, the CC100 has a well-designed frame that provides stability during operation. The weight of the equipment is distributed in a way that helps it maintain its position and counteract the vibrations and forces generated while crushing materials. The sturdy frame not only ensures the proper functioning of the crusher but also contributes to its durability, reducing the likelihood of premature wear and damage caused by excessive movement or instability.

2. Working Principle

When the CC100 is in operation, the 90 - kW motor sets the dynamic cone into rotation at 395 rpm. As the dynamic cone rotates, its eccentric movement, which is adjustable within the 13 - 28 mm range, forces the materials to enter the crushing chamber. Inside the chamber, the materials are subjected to compressive forces between the moving dynamic cone and the fixed parts of the crusher.

Based on the principle of layer - pressure crushing, the CC100 gradually breaks down the materials. The variable eccentricity allows for different levels of crushing force to be applied. A higher eccentricity setting results in a more intense crushing action, which is useful for reducing larger pieces of materials into smaller ones. As the materials are crushed, they move through the crushing chamber and are eventually discharged from the bottom of the crusher. The continuous rotation of the dynamic cone and the repeated application of crushing force ensure a steady flow of crushed materials, maintaining a consistent production rate.

3. Applications and Advantages

The CC100 is widely used in different industries. In the mining sector, it can be employed to process smaller volumes of ores or for initial crushing stages. In construction, it can produce aggregates for various building projects. Its advantages include its relatively high dynamic cone speed for efficient processing, the adjustable eccentricity for versatility in handling different materials, and the stable structure that ensures reliable operation over time. The combination of these features makes it a practical choice for many material crushing tasks where a balance between speed, flexibility, and stability is required.

4. Conclusion

In conclusion, the CC100 single - cylinder cone crusher, with its specific dynamic cone speed, adjustable eccentricity, appropriate motor power, and stable structure, is a valuable asset for material crushing in multiple industries. It offers a reliable and efficient solution that can adapt to a variety of operational requirements, contributing to the overall productivity and quality of the end products.
