CZS24B

CZS24B Cone Crusher: Overview

The CZS24B cone crusher is a highly efficient and reliable piece of equipment that is designed to meet the crushing needs of various industries. Despite its relatively compact size, it offers impressive performance and versatility.

Cavity Types and Their Specifications

C Cavity

The C cavity has a maximum feed size of 60 mm and a discharge opening adjustment range from 3 to 38 mm. It can process materials at a rate within the range of 16 to 50 tons per hour. This cavity type is suitable for applications where a relatively finer crushed product is needed while dealing with moderately sized feed materials.

M Cavity

The M cavity, with a maximum feed size of 80 mm and a discharge opening adjustment range of 10 to 38 mm, can handle a processing capacity between 18 to 65 tons per hour. It is designed to accommodate slightly larger feed materials and produce a broader range of output sizes, making it versatile for different production scenarios.

F Cavity

The F cavity features a maximum feed size of 90 mm and a discharge opening adjustment range from 13 to 38 mm. It has a processing capacity ranging from 22 to 70 tons per hour. This cavity type is ideal for handling larger feed materials and achieving a coarser crushed product with higher throughput.

Processing Capacity

The overall processing capacity of the CZS24B varies depending on the selected cavity type. As mentioned earlier, the C cavity can manage 16 to 50 tons per hour, the M cavity 18 to 65 tons per hour, and the F cavity 22 to 70 tons per hour. This flexibility in processing capacity allows the crusher to adapt to different production demands, whether it's for small to medium-sized operations or those requiring higher output volumes.

Power and Weight Specifications

The CZS24B is powered by a motor with a power of 30 kw. This motor provides sufficient energy to drive the crushing process effectively, ensuring smooth and efficient operation. In terms of weight, the crusher weighs 4.8 tons. Its relatively lightweight design makes it easy to install and relocate if needed, while still maintaining stability during operation.

Overall Dimensions

The overall dimensions of the CZS24B are 1785×1447×1783 mm. These dimensions indicate its compact footprint, which is advantageous in settings where space is limited. It allows for easy integration into existing production lines without taking up excessive space.

Conclusion

In conclusion, the CZS24B cone crusher combines its multiple cavity types, variable processing capacities, appropriate power and weight, and compact size to offer a practical solution for material crushing in various industrial applications. It is a valuable asset for businesses looking for efficient and reliable crushing equipment.

Technical Specifications Table
