Sand Aggregate IndustryComprehensive Service ProviderSand Aggregate IndustryComprehensive Service ProviderJaw Crusher
| model | GC96 |
| Feed opening | 930 x 580 mm |
| CSS Range | 60 - 175 mm |
| Capacity(by hour) | 120 - 325 tph |
| Motor power | 75kW |
| Weight | 9.57 t |
| Rotation speed of eccentric shaft | 330 rpm |
*Note: The processing capacity of the GC96 jaw crusher may vary with different materials and feeding sizes.
The aggregates production line of Huaibei totally meets Anhui actual situation of huge limestone resources. The heavy hammer crusher is adopted to take place traditional jaw crusher and impact crusher.
At that time, the output of the production line of about 1000 tons, in addition to mining equipment, the introduction of intelligent mine management system, to achieve environmental protection production line, intelligent operation management.
It is seen at the production site that the stone with large diameter is entering into the crusher through the feed opening. As for the material with the particle size not exceeding 1.6m we adopt the crusher with large hourly capacity.
The GC96 European Type Jaw Crusher is a highly efficient and reliable crushing equipment suitable for various materials such as river pebbles, granite, basalt, iron ore, limestone, quartz, coal gangue, and construction waste. This crusher incorporates advanced technologies from Metso's C series and Sandvik's JM(CJ) series jaw crushers, combined with domestic practicalities, using advanced computer technology to ensure outstanding performance and reliability.
The GC96 European Type Jaw Crusher has a 30% higher output compared to traditional PE jaw crushers, thanks to its advanced mainframe vibration reduction system, which ensures smoother operation and lower noise levels. It has a feed size of 930 x 580mm, a speed of 330rpm, and a power of 90kW. The output at different closed-side settings (CSS) is as follows: 60mm (120 - 155t/h), 80mm (160 - 210t/h), 100mm (200 - 260t/h), 125mm (250 - 325t/h), 150mm (300 - 390t/h), 175mm (350 - 455t/h). The weight of the unit is 9.57 tons.
The GC96 European Type Jaw Crusher features a modular frame and integrated motor base, saving space and reducing installation costs on-site. The discharge opening adjustment is simple and quick, taking only a few minutes to complete. This design makes installation, operation, and maintenance more convenient, reducing operational costs for users.
